BX10S/00-HB70
BX10S/00-HB70 MICRO DETECTORS Area sensor Emitter 10 beams, with adjustment, plug M12 10-26VDC Sensing dista..
$0.00USD
3630 in stock
Key Specifications
Weight:185g
Emission:Infrared (880nm)
Material:ABS
Approvals:CE
Supplier Information
MICRO DETECTORS
Products: 33669
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Weight | 185g |
| Emission | Infrared (880nm) |
| Material | ABS |
| Approvals | CE |
| Dimensions | 16x37x64 |
| Connections | Right angle cable exit |
| Output type | DECOUT (PNP, NPN, NO, NC selectable) |
| Load current | 100mA |
| LED indicators | Red ( output energized) |
| Optic position | Axial |
| Leakage current | ≤ 10μA |
| Output Function | NO, NC selectable |
| Repeat Accuracy | ≤ 5% |
| EMC compatibility | EN 60947-5-2 |
| Operating Voltage | 10-30Vdc |
| Function Principle | Diffuse reflection |
| Max ripple content | ≤ 10% |
| Output voltage drop | 1,2V max |
| Switching frequency | 80Hz |
| Active Head Material | PMMA |
| Degree of protection | IP65 |
| Supplied Accessories | ST01 mounting brakets and screws |
| Operating temperature | - 25°C…+ 70°C ( without freeze) |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-29 |
| No-Load supply current | 25mA max |
| Sensitivity adjustment | 1 turn trimmer |
| Nominal sensing distance | 100mm |
| Short-circuit protection | Yes |
| Reverse Polarity Protection | Yes |
| Interference to external light | 3000lux Incandescent Lamp, 10000lux |
| Time delay before availability | 200ms |
Product Description
BX10S/00-HB70 Area sensor Emitt. 10 beamsadj.conn. M12 10-26VDCSn = 100-300 mm
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
