BCVP-381R- 8 GN
BCVP-381R- 8 GN 5449584 PHOENIX CONTACT Part plug,nominal Current: 8 A,rated Voltage (III/2): 160 V,N. º pol..
$0.00USD
4574 in stock
Key Specifications
GTIN:4046356840026
Note:Made to Order (non-returnable)
Orderkey:5449584
Packing unit:50 pc
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| GTIN | 4046356840026 |
| Note | Made to Order (non-returnable) |
| Orderkey | 5449584 |
| Packing unit | 50 pc |
| Country of origin | DE (Germany) |
| (Connection data) | CUL |
| Custom tariff number | 85366990 |
| Minimum order quantity | 100 pc |
| Screw thread (Dimensions) | M2 |
| Pitch (Key Commercial Data) | 3.81 mm |
| (Standards and Regulations) | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
| Stripping length (Dimensions) | 7 mm |
| Connection method (Dimensions) | Screw connection with tension sleeve |
| Range of articles (Dimensions) | BCVP-R |
| Nominal current IN (Dimensions) | 8 A |
| Insulating material (Dimensions) | PA |
| Number of positions (Dimensions) | 8 |
| Dimension a (Key Commercial Data) | 26.67 mm |
| Maximum load current (Dimensions) | 8 A (with 1.5 mm² conductor cross section) |
| Rated voltage (II/2) (Dimensions) | 320 V |
| Height [ h ] (Key Commercial Data) | 12.5 mm |
| Nominal cross section (Dimensions) | 1.5 mm² |
| Rated voltage (III/2) (Dimensions) | 160 V |
| Rated voltage (III/3) (Dimensions) | 160 V |
| Tightening torque max (Dimensions) | 0.25 Nm |
| Tightening torque, min (Dimensions) | 0.22 Nm |
| Weight per Piece (excluding packing) | 6.670 g |
| China RoHS (Standards and Regulations) | Environmentally Friendly Use Period = 50 |
| Insulating material group (Dimensions) | I |
| REACh SVHC (Standards and Regulations) | Lead 7439-92-1 |
| Rated surge voltage (II/2) (Dimensions) | 2.5 kV |
| Rated surge voltage (III/2) (Dimensions) | 2.5 kV |
| Rated surge voltage (III/3) (Dimensions) | 2.5 kV |
| Conductor cross section AWG max. (General) | 16 |
| Conductor cross section AWG min. (General) | 24 |
| Conductor cross section solid max. (General) | 1.5 mm² |
| Conductor cross section solid min. (General) | 0.2 mm² |
| Connection in acc. with standard (Dimensions) | EN-VDE |
| Conductor cross section flexible max. (General) | 1.5 mm² |
| Conductor cross section flexible min. (General) | 0.2 mm² |
| Connection in acc. with standard (Connection data) | EN-VDE |
| Flammability rating according to UL 94 (Dimensions) | V0 |
| Flammability rating according to UL 94 (Connection data) | V0 |
| 2 conductors with same cross section, solid max. (General) | 0.5 mm² |
| 2 conductors with same cross section, solid min. (General) | 0.2 mm² |
| 2 conductors with same cross section, stranded max. (General) | 0.75 mm² |
| 2 conductors with same cross section, stranded min. (General) | 0.2 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve max. (General) | 0.5 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve min. (General) | 0.25 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve max. (General) | 1.5 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve min. (General) | 0.25 mm² |
| 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max. (General) | 0.34 mm² |
| 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min. (General) | 0.25 mm² |
| 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max. (General) | 0.5 mm² |
| 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min. (General) | 0.5 mm² |
