BCP-508F-2 BK
BCP-508F- 2 BK 5452568 PHOENIX CONTACT Part plug,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º pol..
$0.00USD
4436 in stock
Key Specifications
Ean:4046356850131
Sell key:AAYBAA -
Order key:5452568
Packaging unit:100 pcs
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Ean | 4046356850131 |
| Sell key | AAYBAA - |
| Order key | 5452568 |
| Packaging unit | 100 pcs |
| Country of origin | CN (China) |
| Tariff rate number | 85366990 |
| Isolation (Dimensions) | PA |
| Minimum Order Quantity | 100 pcs |
| Step (Commercial data) | 5.08 mm |
| Screw thread (Dimensions) | M3 |
| Article Family (Dimensions) | BCP-F |
| Medium to (Commercial data) | 5.08 mm |
| Connection type (Dimensions) | Screw connection with traction capsule |
| Nominal Section (Dimensions) | 2.5 mm² |
| Number of poles (Dimensions) | 2 |
| (Standards & Specifications) | You can find information about hazardous substances in the manufacturer's declaration under the "Downloads" tab |
| Width [ w ] (Commercial data) | 20.18 mm |
| Height [ h ] (Commercial data) | 15 mm |
| Length [ l ] (Commercial data) | 18.2 mm |
| Nominal Current IN (Dimensions) | 12 A |
| Sizing voltage (II/2) (Dimensions) | 630 V |
| Max. tightening torque. (Dimensions) | 0.5 Nm |
| Min. tightening torque. (Dimensions) | 0.4 Nm |
| Maximum Charging Current (Dimensions) | 12 A (with a conductor cross-section of 2.5 mm²) |
| Weight per unit (excluding packaging) | 4,272 g |
| Insulating material group (Dimensions) | I |
| Length to be de-insulated (Dimensions) | 7 mm |
| China RoHS (Standards & Specifications) | Time Span for Intended Use (EFUP): 50 years |
| REACh SVHC (Standards & Specifications) | Lead 7439-92-1 |
| Standard-compliant connection (General) | CUL |
| Dimensioning voltage (III/2) (Dimensions) | 320 V |
| Combustibility class according to UL 94 (General) | V0 |
| Dimensioning transient voltage (II/2) (Dimensions) | 4 kV |
| Dimensioning Transient Voltage (III/2) (Dimensions) | 4 kV |
| Dimensioning transient voltage (III/3) (Dimensions) | 4 kV |
| Combustibility class according to UL 94 (Dimensions) | V0 |
Product Description
Connector for printed circuit board, nominal section: 2.5 mm², color: black, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Female, number of potentials: 2,
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
