BCH-508H-8 GN
BCH-508H- 8 GN 5446370 PHOENIX CONTACT Printed-circuit board connector
$0.00USD
4971 in stock
Key Specifications
EAN:Four trillion forty six billion three hundred fifty six million eight hundred thirty two thousand eight hundred ninety two
Key order:Five million four hundred forty six thousand three hundred seventy
(Drawings):
(Overview):CUL
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | Four trillion forty six billion three hundred fifty six million eight hundred thirty two thousand eight hundred ninety two |
| Key order | Five million four hundred forty six thousand three hundred seventy |
| (Drawings) | |
| (Overview) | CUL |
| Key selling | AAYBFA - |
| Packing unit | 100 pcs |
| Step (Drawings) | 5,08 mm |
| UNSPSC 11 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| Width (Drawings) | 40,64 mm |
| Country of origin | CN (China) |
| ETIM 3.0 (eCl@ss) | EC001121 |
| ETIM 4.0 (eCl@ss) | EC002637 |
| ETIM 5.0 (eCl@ss) | EC002637 |
| ETIM 6.0 (eCl@ss) | EC002637 |
| ETIM 7.0 (eCl@ss) | EC002637 |
| Length (Drawings) | 12 mm |
| Average (Drawings) | 35,56 mm |
| Color (Dimensions) | whitish green |
| UNSPSC 13.2 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 18.0 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 19.0 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 20.0 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 21.0 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 6.01 (ETIM) | Thirty million two hundred eleven thousand eight hundred one |
| UNSPSC 12.01 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred nine |
| Tariff number tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
| UNSPSC 7.0901 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| eCl@ss 4.0 (Ratings) | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 4.1 (Ratings) | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 5.0 (Ratings) | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 5.1 (Ratings) | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 6.0 (Ratings) | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 7.0 (Ratings) | Twenty seven million four hundred forty thousand four hundred two |
| eCl@ss 8.0 (Ratings) | Twenty seven million four hundred forty thousand four hundred two |
| eCl@ss 9.0 (Ratings) | Twenty seven million four hundred forty thousand four hundred two |
| Isolation (Dimensions) | PA |
| Minimum order quantity | 100 pcs |
| Width [ w ] (Drawings) | 40,64 mm |
| Height [ h ] (Drawings) | 12,1 mm |
| Length [ l ] (Drawings) | 12 mm |
| Dimensions of pin (Drawings) | 1 x 1 mm |
| Number of poles (Dimensions) | Eight |
| (Standards and specifications) | No dangerous substances above the thresholds |
| Family of articles (Dimensions) | BCH-H |
| Nominal current IN (Dimensions) | 12 To |
| Height of construction (Drawings) | 8.6 mm |
| Maximum load current (Dimensions) | 12 To |
| Unit weight (excluding packaging) | 2,927 g |
| Length of the pin welding (Drawings) | 3.5 mm |
| Group insulating material (Dimensions) | I |
| Tension and sizing (II/2) (Dimensions) | 400 V |
| Tension and sizing (III/2) (Dimensions) | 320 V |
| Tension and sizing (III/3) (Dimensions) | 250 V |
| China RoHS (Standards and specifications) | Space of time for the intended use: unlimited = FEUP-e |
| Connection according to standard (Overview) | EN-VDE |
| Transient voltage design (II/2) (Dimensions) | 4 kV |
| Connection according to standard (Dimensions) | EN-VDE |
| Transient voltage design (III/2) (Dimensions) | 4 kV |
| Transient voltage design (III/3) (Dimensions) | 4 kV |
| Class of flammability according to UL 94 (Overview) | V0 |
| Class of flammability according to UL 94 (Dimensions) | V0 |
Product Description
Printed circuit board base housing, nominal section: 2.5 mm², color: whitish green, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact connection type: Male, number o
