In Stock Hot Product
AMMP 63/36
AMMP 63/36 10063937 WISKA Hexagonal converter. metallic thread ext. M63, thread int. PG.36
$0.00USD
3242 in stock
Key Specifications
Form (Features):B
Type (Features):AMMP 63/36
Surface (Features):Nickel-plated
Material (Features):Brass nickel-plated
Supplier Information
WISKA
Products: 2869
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Form (Features) | B |
| Type (Features) | AMMP 63/36 |
| Surface (Features) | Nickel-plated |
| Material (Features) | Brass nickel-plated |
| Lead outer (Features) | 1,5 |
| Key width SW (Features) | 66 mm |
| Packing unit (Features) | 10 |
| Temp. range max (Features) | 250 °C |
| Temp. range min (Features) | -200 °C |
| Total length TL (Features) | 14 mm |
| Ø inner thread (Features) | 36 |
| Ø outer thread (Features) | 63 |
| Thread type inner (Features) | PG |
| Thread type outer (Features) | M |
| Collar diameter (E) (Features) | 79 mm |
| ETIM-Classification (Features) | EC000938 |
| External diameter ED (Features) | 68 mm |
| Order no. nickel-plated (Features) | 10063937 |
| Length screw-in thread L (Features) | 10 mm |
Product Description
Adaptor, brass nickel-plated, M63 / Pg36
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
