AK1/AP-3HAN
AK1/AP-3HAN MICRO DETECTORS Inductive sensor M18 shielded LD NO/PNP plug M12 II 3G Ex nA IIC T5, II 3D Ex tD..
$0.00USD
3297 in stock
Key Specifications
Weight:30g
Mounting:Flush
Dimensions:Ø3 / L = 22mm
Hysteresis:1 ... 20%
Supplier Information
MICRO DETECTORS
Products: 33669
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Weight | 30g |
| Mounting | Flush |
| Dimensions | Ø3 / L = 22mm |
| Hysteresis | 1 ... 20% |
| Connections | Cable PUR 2m |
| Output type | NPN |
| Load current | ≤ 100mA |
| Exit function | NOT |
| Nominal range | 0.6 mm |
| Repeatability | 5% (UB 24V Ta=23°C ±5°C) |
| Thermal drift | < 10% |
| body material | Stainless steel AISI303 |
| Certifications | CEUL |
| LED indicators | Yellow LED output status |
| Supply voltage | 10 - 30vdc |
| Leakage current | ≤ 10µA |
| Operating range | 0...0,48 mm |
| Object reference | 4x4mm FE360 |
| Correction Factor | copper: 0,32 ± 10% / aluminum: 0,24 ± 10% / brass: 0,39 ± 10% / stainless Steel: 0,57 ± 10% |
| Shock and vibration | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 |
| Switching frequency | 3kHz |
| Degree of protection | IP 67 (EN60529) |
| Operating temperature | -25°C...+70°C |
| Maximum residual ripple | ≤10% |
| Protection short circuit | Yes |
| Delay to the availability | ≤ 50ms |
| Voltage drop to the output | ≤ 1.5 V @100mA |
| Protection polarity reversal | Yes |
| Electromagnetic compatibility | IEC 60947-5-2 |
| Material of the active surface | PBT |
| Protection against inductive loads | Yes |
| Absorption of current in the vacuum | ≤ 10mA |
Product Description
AK1/AP-3HAN Inductive sensor M18 shielded LD NO/PNP conn. M12ATEX CAT.3 GROUP 2/22
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
