A210-30-11-80
A210-30-11-80 1SFL511001R8011 ABB 3-phase contactor 220-230V 50Hz / 230-240V 60Hz
$0.00USD
3316 in stock
Key Specifications
Customs Tariff Number::85364900
Minimum Order Quantity::1 piece
RoHS Status: (Technical):Following EU Directive 2002/95/EC August 18, 2005 and amendment
Operate Time: (Dimensions):Between Coil Energization and NO Contact Closing 17 ... 35 msBetween Coil De-energization and NO Contact Opening 10 ... 16 msBetween Coil De-energization and NC Contact Closing 7 ... 13 msBetween Coil Energization and NC Contact Opening 12 ... 30 ms
Supplier Information
ABB
Products: 44170
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Customs Tariff Number: | 85364900 |
| Minimum Order Quantity: | 1 piece |
| RoHS Status: (Technical) | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
| Operate Time: (Dimensions) | Between Coil Energization and NO Contact Closing 17 ... 35 msBetween Coil De-energization and NO Contact Opening 10 ... 16 msBetween Coil De-energization and NC Contact Closing 7 ... 13 msBetween Coil Energization and NC Contact Opening 12 ... 30 ms |
| Terminal Type: (Dimensions) | Main Circuit: Bars |
| Dimension Diagram: (Ordering) | 53540930-2 |
| Replacement Product ID (NEW): | 1SFL527002R1311 |
| Coil Consumption: (Dimensions) | Pull-in at Max. Rated Control Circuit Voltage 60 Hz 1550 V·AHolding at Max. Rated Control Circuit Voltage 50 Hz 60 V·APull-in at Max. Rated Control Circuit Voltage 50 Hz 1350 V·AHolding at Max. Rated Control Circuit Voltage 60 Hz 65 V·A |
| ETIM 4: (Container Information) | EC000066 - Magnet contactor, AC-switching |
| ETIM 5: (Container Information) | EC000066 - Magnet contactor, AC-switching |
| ETIM 6: (Container Information) | EC000066 - Power contactor, AC switching |
| ETIM 7: (Container Information) | EC000066 - Power contactor, AC switching |
| UNSPSC: (Container Information) | 39121529 |
| E-nummer: (Container Information) | 3227874 |
| Rated Frequency (f): (Dimensions) | Main Circuit 50/60 Hz |
| BV Certificate: (Technical UL/CSA) | 09826/C0 BV |
| Degree of Protection: (Dimensions) | acc. to IEC 60529, IEC 60947-1, EN 60529 Coil Terminals IP20acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP00 |
| GL Certificate: (Technical UL/CSA) | GL_15529-00HH |
| LR Certificate: (Technical UL/CSA) | LR_12-70003 |
| CCC Certificate: (Technical UL/CSA) | CQC_2008010304279325 |
| Coil Operating Limits: (Dimensions) | (acc. to IEC 60947-4-1) 0.85 x Uc Min. ... 1.1 x Uc Max. (at θ ≤ 70 °C) °C |
| DNV Certificate: (Technical UL/CSA) | DNV_E-12191 |
| Mechanical Durability: (Dimensions) | 5 million |
| Ambient Air Temperature: (Technical) | Close to Contactor Fitted with Thermal O/L Relay (0.85 ... 1.1 Uc) -25 ... +50 °CClose to Contactor without Thermal O/L Relay (0.85 ... 1.1 Uc) -40 ... +70 °CClose to Contactor for Storage -40 ... +70 °C |
| Instructions and Manuals: (Ordering) | 1SFC380003-89 |
| RINA Certificate: (Technical UL/CSA) | ELE060313XG/001 |
| RMRS Certificate: (Technical UL/CSA) | RMRS_12-03683-315 |
| RoHS Information: (Technical UL/CSA) | 1SFC101046D0203 |
| LOVAG Certificate: (Technical UL/CSA) | IT99036 |
| Product Net Width: (Popular Downloads) | 140.0 mm |
| Maximum Breaking Capacity: (Dimensions) | cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 440 V 2200 Acos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 690 V 2000 A |
| Product Net Height: (Popular Downloads) | 227.0 mm |
| Product Net Weight: (Popular Downloads) | 5.750 kg |
| Rated Operational Voltage: (Dimensions) | Main Circuit 690 V |
| Number of Main Contacts NC: (Dimensions) | 0 |
| Number of Main Contacts NO: (Dimensions) | 3 |
| Horsepower Rating UL/CSA: (Environmental) | (208 V AC) Three Phase 60 Hp(440 ... 480 V AC) Three Phase 150 Hp(550 ... 600 V AC) Three Phase 200 Hp(220 ... 240 V AC) Three Phase 75 Hp(200 V AC) Three Phase 60 Hp |
| General Use Rating UL/CSA: (Environmental) | (600 V AC) 300 A |
| Rated Insulation Voltage (Ui): (Dimensions) | acc. to UL/CSA 600 Vacc. to IEC 60947-4-1 and VDE 0110 (Gr. C) 1000 V |
| Instructions and Manuals: (Technical UL/CSA) | 1SFC380003-89 |
| Data Sheet, Technical Information: (Ordering) | 1SBC100122C0202 |
| Environmental Information: (Technical UL/CSA) | 1SFC101003D0201 |
| Number of Auxiliary Contacts NC: (Dimensions) | 1 |
| Number of Auxiliary Contacts NO: (Dimensions) | 1 |
| Connecting Capacity Main Circuit: (Dimensions) | Rigid Al-Cable 2 x 95 ... 120 mm²Bar 32 mmRigid Cu-Cable 16 ... 240 mm² |
| Short-Circuit Protective Devices: (Dimensions) | gG Type Fuses 400 A |
| Product Net Depth / Length: (Popular Downloads) | 180.5 mm |
| Rated Operational Power AC-3 (Pe): (Dimensions) | (500 V) 132 kW(690 V) 160 kW(220 / 230 / 240 V) 59 kW(380 / 400 V) 110 kW(440 V) 110 kW(415 V) 110 kW |
| Rated Control Circuit Voltage (Uc): (Dimensions) | 60 Hz 230 ... 240 V50 Hz 220 ... 230 V |
| Maximum Operating Voltage UL/CSA: (Environmental) | Main Circuit 600 V |
| Rated Operational Current AC-1 (Ie): (Dimensions) | (690 V) 55 °C 300 A(690 V) 40 °C 350 A(690 V) 70 °C 240 A |
| Rated Operational Current AC-3 (Ie): (Dimensions) | (690 V) 55 °C 210 A(220 / 230 / 240 V) 55 °C 210 A(415 V) 55 °C 210 A(440 V) 55 °C 210 A(380 / 400 V) 55 °C 210 A(500 V) 55 °C 210 A |
| Rated Operational Current DC-1 (Ie): (Dimensions) | (110 V) 2 Poles in Series, 40 °C 350 A(220 V) 3 Poles in Series, 40 °C 350 A |
| Rated Operational Current DC-3 (Ie): (Dimensions) | (110 V) 2 Poles in Series, 40 °C 350 A(220 V) 3 Poles in Series, 40 °C 350 A |
| Rated Operational Current DC-5 (Ie): (Dimensions) | (110 V) 2 Poles in Series, 40 °C 350 A(220 V) 3 Poles in Series, 40 °C 350 A |
| Declaration of Conformity - CE: (Technical UL/CSA) | 2CMT2015-005436 |
| Connecting Capacity Auxiliary Circuit: (Dimensions) | Solid 2 x 1 ... 4 mm²Flexible with Insulated Ferrule 1 x 0.75 ... 2.5 mm²Stranded 2 x 1 .... 4 mm²Flexible 2x0.75 ... 2.5 mm²Flexible with Ferrule 2 x 0.75 ... 2.5 mm² |
| Maximum Operating Altitude Permissible: (Technical) | 3000 m |
| Object Classification Code: (Container Information) | Q |
| Maximum Electrical Switching Frequency: (Dimensions) | AC-3 300 cycles per hourAC-1 300 cycles per hourAC-2 / AC-4 150 cycles per hour |
| Maximum Mechanical Switching Frequency: (Dimensions) | 3600 cycles per hour |
| Rated Impulse Withstand Voltage (Uimp): (Dimensions) | Main Circuit 8 kV |
| Rated Short-time Withstand Current (Icw): (Dimensions) | at 40 °C Ambient Temp, in Free Air, from a Cold State 30 s 1200 Aat 40 °C Ambient Temp, in Free Air, from a Cold State 15 min 400 Aat 40 °C Ambient Temp, in Free Air, from a Cold State 10 s 1700 Aat 40 °C Ambient Temp, in Free Air, from a Cold State 1 s 2500 Aat 40 °C Ambient Temp, in Free Air, from a Cold State 1 min 1000 A |
| Resistance to Shock acc. to IEC 60068-2-27: (Technical) | Shock Direction: A 5 gShock Direction: C2 5 gShock Direction: C1 5 gShock Direction: B2 5 gShock Direction: B1 5 g |
| Conventional Free-air Thermal Current (Ith): (Dimensions) | acc. to IEC 60947-4-1, Open Contactors q = 40 °C 350 A |
| Rated Making Capacity AC-3 acc. to IEC 60947-4-1: (Dimensions) | 10 x Ie AC-3 |
| Rated Breaking Capacity AC-3 acc. to IEC 60947-4-1: (Dimensions) | 8 x Ie AC-3 |
| Package Level 1 EAN: (Certificates and Declarations (Document Number)) | 7320500203323 |
| Package Level 1 Units: (Certificates and Declarations (Document Number)) | 1 piece |
| Package Level 1 Width: (Certificates and Declarations (Document Number)) | 200 mm |
| Package Level 1 Height: (Certificates and Declarations (Document Number)) | 280 mm |
| Connecting terminals (delivered in open position) Main poles: (Dimensions) | Flat type c/w screws and bolts |
| Package Level 1 Gross Weight: (Certificates and Declarations (Document Number)) | 5.75 kg |
| Package Level 1 Depth / Length: (Certificates and Declarations (Document Number)) | 220 mm |
