| Parameter | Value |
|---|---|
| PH | S15 |
| MODEL | S15-PA-3-D50-NK |
| SERIES | S15 |
| Setting | NULL |
| ORDER No | 952301550 |
| Case form | M18 tubular |
| Protection | IP67 |
| Output type | NPN |
| Power supply | 10…30 VDC |
| Case material | Plastic |
| Light emission | LED - Infrared |
| Optic function | Fixed focus proximity |
| Connection type | Pig-tail with M12 conn |
| Controlled height | NULL |
| Sensing range max | a) ≤ 100 mm |
