8WH1000-0AF08
8WH1000-0AF08 SIEMENS Terminal block, 2.5 mm2 black Screw mounting 2 connections Black
$0.00USD
3110 in stock
Key Specifications
:VersionClassificationeClass627-14-11-20eClass7.127-14-11-20eClass827-14-11-20eClass927-14-11-20eClass9.127-14-11-20ETIM5EC000897ETIM6EC000897ETIM7EC000897ETIM8EC000897UNSPSC1439-12-14-10UNSPSC1539-12-14-10
EAN:4001869500157
UPC:887621581183
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| VersionClassificationeClass627-14-11-20eClass7.127-14-11-20eClass827-14-11-20eClass927-14-11-20eClass9.127-14-11-20ETIM5EC000897ETIM6EC000897ETIM7EC000897ETIM8EC000897UNSPSC1439-12-14-10UNSPSC1539-12-14-10 | |
| EAN | 4001869500157 |
| UPC | 887621581183 |
| ETIM | 5 |
| UNSPSC | 14 |
| eClass | 6 |
| Group Code | P310 |
| Metal Factor | None |
| Product Group | 5555 |
| Product class | B: return restricted, please contact your Siemens partner/contact |
| Quantity Unit | 1 Piece |
| Commodity Code | 85369010 |
| Product family | 8WH terminals |
| Net Weight (kg) | 0,008 Kg |
| Colour (EF000007) | Black |
| Country of origin | Germany |
| Length (EF001438) | 47.7 |
| LKZ_FDB/ CatalogID | LV10.2 |
| Packaging Quantity | 1 |
| Packaging Dimension | 40,00 x 52,00 x 3,00 |
| Product Description | Terminal block, 2.5 mm2 black Screw mounting 2 connections Black |
| Minimum order quantity | 50 |
| Product Lifecycle (PLM) | PM300:Active Product |
| Rated voltage (EF000228) | 1000 |
| Export Control Regulations | AL : N / ECCN : N |
| Mounting method (EF000003) | DIN rail (top hat rail) 35 mm |
| Number of levels (EF002659) | 1 |
| Rated current In (EF008250) | 24.0 |
| Standard lead time ex-works | 5 Day/Days |
| Surcharge for Raw Materials | None |
| Package size unit of measure | MM |
| Connection position (EF008219) | Sideways |
| Width/grid dimension (EF002522) | 2.5 |
| Operating temperature (EF002393) | ['-25', '55'] |
| Closing plate required (EF002525) | true |
| Material insulation body (EF007543) | Thermoplastic |
| Article Number (Market Facing Number) | 8WH1000-0AF08 |
| Internally connected stages (EF002661) | false |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| Explosion-tested version 'Ex e' (EF008498) | false |
| Type of electrical connection 1 (EF002526) | Screw connection |
| Type of electrical connection 2 (EF002527) | Screw connection |
| Number of clamp positions per level (EF002660) | 2 |
| Height at lowest possible mounting height (EF002523) | 47.5 |
| Region Specific PriceGroup / Headquarter Price Group | 12X / 1BT |
| Connectable conductor cross section solid-core (EF007337) | ['0.14', '4.0'] |
| Connectable conductor cross section multi-wired (EF007343) | - |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.09.2013 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Lead CAS-No. 7439-92-1 > 0, 1 % (w / w)Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w):LeadBased on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation. |
| Inflammability class of insulation material according to with UL94 (EF002521) | V0 |
| Connectable conductor cross section fine-strand with cable end sleeve (EF007339) | - |
| Connectable conductor cross section fine-strand without cable end sleeve (EF007341) | - |
Product Description
TERMINAL FOR RAIL, 2,5MM2 BLACK SCREW FIXING 2 BLACK CONNECTIONS ( ** ATTENTION : Price per 1 Unit and Minimum Quantity / Order Multiple 50 Units ** ). Cancelations and returns limited. Consult condit
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w):
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
