8WA1604
8WA1604 SIEMENS N isolating terminal thermoplast Screw terminal blue, 10mm, Size 16
$0.00USD
3014 in stock
Key Specifications
:
EAN:4011209156883
UPC:754554224541
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4011209156883 |
| UPC | 754554224541 |
| ETIM | 5 |
| Notes | Sucessor:8WH10010BK01 |
| color | blue |
| UNSPSC | 14 |
| eClass | 6 |
| length | 55 mm |
| Group Code | P310 |
| net weight | 27 g |
| ● maximum | 16 mm² |
| ● minimum | 16 mm² |
| Confirmation | |
| Metal Factor | None |
| Date5/16/2022 | |
| Product Group | 5565 |
| Product class | D: products made to order / customer's specifications, requiring engineering services, which cannot be re-used or utilized (design to customer) |
| Quantity Unit | 1 Piece |
| busbar design | 6x6 mm |
| Commodity Code | 85369010 |
| Product family | 8WA terminals |
| Net Weight (kg) | 0,027 Kg |
| stripped length | 13 mm |
| fastening method | others |
| Colour (EF000007) | Blue |
| Country of origin | Greece |
| Length (EF001438) | 55.0 |
| LKZ_FDB/ CatalogID | LV10.2 |
| PLM Effective Date | Product phase-out since: 01.08.2021 |
| Packaging Quantity | 1 |
| product brand name | ALPHA |
| Packaging Dimension | 105,00 x 293,00 x 51,00 |
| Product Description | N isolating terminal thermoplast Screw terminal blue, 10mm, Size 16 |
| insulation material | thermoplastic |
| Minimum order quantity | 50 |
| Product Lifecycle (PLM) | PM400:Phase Out Started |
| General Product Approval | Declaration of Conformity |
| Rated voltage (EF000228) | 500 |
| terminal contact spacing | 10 mm |
| number of terminal points | 1 |
| Export Control Regulations | AL : N / ECCN : N |
| Mounting method (EF000003) | Other |
| Environmental Confirmations | |
| Rated current In (EF008250) | 76.0 |
| Standard lead time ex-works | 7 Day/Days |
| Surcharge for Raw Materials | None |
| Package size unit of measure | MM |
| type of electrical connection | screw-type terminals |
| Width/grid dimension (EF002522) | 10.0 |
| operating voltage / rated value | 500 V |
| Operating temperature (EF002393) | ['-', '-'] |
| Suitable for N-busbar (EF002557) | 6x6 mm |
| material / of the insulating body | Thermoplast |
| operational current / rated value | 76 A |
| Material insulation body (EF007543) | Thermoplastic |
| Connecting plate required (EF002528) | false |
| Number of clamp positions (EF000584) | 1 |
| Article Number (Market Facing Number) | 8WA1604 |
| Type of electric connection (EF003961) | Screw connection |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| ● with core end processing / maximum | 16 mm² |
| ● with core end processing / minimum | 16 mm² |
| combustibility class according to UL 94 | others |
| height / with lowest-profile installation | 35 mm |
| ● without core end processing / maximum | 16 mm² |
| ● without core end processing / minimum | 16 mm² |
| connectable conductor cross-section / solid | |
| tightening torque / with screw-type terminals | |
| connectable conductor cross-section / stranded | |
| product component / required / end cover plate | No |
| Height at lowest possible mounting height (EF002523) | 35.0 |
| Region Specific PriceGroup / Headquarter Price Group | 12W / 1BT |
| connectable conductor cross-section / finely stranded | |
| Connectable conductor cross section solid-core (EF007337) | ['16.0', '16.0'] |
| Connectable conductor cross section multi-wired (EF007343) | ['16.0', '16.0'] |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.07.2006 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Lead CAS-No. 7439-92-1 > 0, 1 % (w / w)Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w):LeadBased on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation. |
| Inflammability class of insulation material according to with UL94 (EF002521) | Other |
| Connectable conductor cross section fine-strand with cable end sleeve (EF007339) | ['16.0', '16.0'] |
| Connectable conductor cross section fine-strand without cable end sleeve (EF007341) | ['16.0', '16.0'] |
| General Product ApprovalDeclaration of ConformityTest CertificatesotherConfirmationMiscellaneousMiscellaneousotherEnvironmental Confirmations | General Product Approval |
Product Description
Separation terminal N thermal insulating material, screw connection, blue, 10mm, size 16 (** ATTENTION : Price per 1 Unit and Minimum Quantity / Order Multiple 50 Units ** ). Manufactured to customer
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
