880930
880930 GENERAL ELECTRIC Moduclic 8 cables for 2 x 4P MCB's 6 black & 2 blue 6 mm² l 320 mm
$0.00USD
3728 in stock
Key Specifications
IP:IP20
Type:Cables for 2 x 4P MCB’s 6 mm²
Standards:IEC 60439-1
Family Name:QuiXtra 630
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| IP | IP20 |
| Type | Cables for 2 x 4P MCB’s 6 mm² |
| Standards | IEC 60439-1 |
| Family Name | QuiXtra 630 |
| Enclosure type | Cabinet |
| Standard packing | 1 |
| (SPECIFICATIONS) | 320 mm |
| Number of modules | 24 |
| Product/Accessory | Accessory |
| ETIM 5.0 (DIMENSIONS) | EC000057 |
| ETIM 6.0 (DIMENSIONS) | EC000057 |
| Product/Accessory functionality | Moduclic plug-in distribution system |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Moduclic is a secondary busbar system of 250A, 660V~ 60kA peak. Moduclic is an incoming busbar for modular devices and this as well for MCB's as for comfort functions. The Moduclic is mounted directly on the DIN-rail and is independent from the type of system enclosure: Modula or VP-System. The main advantage of the Moduclic is the safety aspect (IP20): adding or removing electrical circuits in a panel board without disconnecting the power. All outgoing circuits stay in the operational function, due to the fact that all operations are done using the insulated Click connection, without touching the parts on tension, even not when using an insulated tool. Standard connections of 6 mm² (up to 40A) are shipped with the Moduclic. The Moduclic busbar system is suitable for integration in all system enclosures conform to IEC 60439-1.
