866184 MURRELEKTRONIK MST single-phase control and isolation transformer P:160VA IN:400/440VAC OUT:115/230VAC
$0.00USD
3833 in stock
Key Specifications
EAN:4048879330480
eClass:27031202
Frequency:50...60 Hz
Standards:EN 61558-2-4, EN 62041 category 0
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879330480 |
| eClass | 27031202 |
| Frequency | 50...60 Hz |
| Standards | EN 61558-2-4, EN 62041 category 0 |
| Drill hole Ø | 4.8×8.4 mm |
| Input current | 0.48 A (400 V AC); 0.44 A (440 V AC) |
| Input voltage | 400, 440 V AC |
| Output rating | 160 VA |
| Inrush current | 3.8 A (400 V AC); 3.5 A (440 V AC) |
| Output voltage | 1× 230, 1× 115, 2× 115 V AC |
| Packaging unit | 1 |
| Mounting method | Long-hole mounting |
| Temperature range | -20...+40 °C (storage temperature -40...+80 °C) |
| country of origin | CZ |
| Dimensions H×W×D | 107.4×96×106 mm |
| Short-circuit current | 6.7 A (400 V AC); 6.1 A (440 V AC) |
| customs tariff number | 85043180 |
| Fixing centers a×b×c | 86.5×84×4.8 mm |
| Test isolation voltage | 5.9 kV |
Product Description
MST SINGLE-PHASE CONTROL AND ISOLATION TRANSFORMER
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
