In Stock Hot Product
866062
866062 MURRELEKTRONIK MST single-phase control and isolation transformer P:63VA IN:230/400VAC±15VAC OUT:230V..
$0.00USD
4477 in stock
Key Specifications
EAN:4048879073950
eClass:27031202
Frequency:50...60 Hz
Standards:EN 61558-2-4, EN 62041 category 0
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879073950 |
| eClass | 27031202 |
| Frequency | 50...60 Hz |
| Standards | EN 61558-2-4, EN 62041 category 0 |
| Input current | 0.32 A (230 V AC); 0.18 A (400 V AC) |
| Input voltage | 230/400 ±15 V AC |
| Output rating | 63 VA |
| Inrush current | 2.2 A (230 V AC); 1.3 A (400 V AC) |
| Output voltage | 230 V AC |
| Packaging unit | 1 |
| Mounting method | Key-hole mounting |
| Temperature range | -20...+40 °C (storage temperature -40...+80 °C) |
| country of origin | CZ |
| Dimensions H×W×D | 69×78×90 mm |
| Short-circuit current | 2.9 A (230 V AC); 1.7 A (400 V AC) |
| customs tariff number | 85043180 |
| Fixing centers a×b×c | 47.5×56×4.8 mm |
| Test isolation voltage | 4.7 kV |
Product Description
MST SINGLE-PHASE CONTROL AND ISOLATION TRANSFORMER
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
