86472 MURRELEKTRONIK MTL single-phase control and isolation transformer P: 63VA IN: 230/400VAC +/- 15VAC OUT..
$0.00USD
3267 in stock
Key Specifications
EAN:4048879078214
eClass:27031302
Weight::2 kg
Art.No.::86472
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879078214 |
| eClass | 27031302 |
| Weight: | 2 kg |
| Art.No.: | 86472 |
| Frequency | 50...60 Hz |
| Standards | EN 61558-1, EN 61558-2-4, EN 62041 category 0 |
| LED display | LED (green) for input voltage |
| Drill hole Ø | 5.5×9 mm |
| Input current | 0.4 A (230 V AC); 0.23 A (400 V AC) |
| Input voltage | 230/400 ±15 V AC |
| Output rating | 63 VA |
| Inrush current | 5.35 A (230 V AC); 3.09 A (400 V AC) |
| Output voltage | 1 × 230, 1 × 115, 2 × 115 V AC |
| Packaging unit | 1 |
| Mounting method | DIN-rail mountable TH35-15 (EN 60715) or for key-hole mounting |
| Temperature range | -20...+60 °C, no condensation |
| country of origin | CZ |
| Short-circuit current | 7.2 A (230 V AC); 4.16 A (400 V AC) |
| customs tariff number | 85043180 |
| Dimensions H × W × D | 108×87×116 mm |
| Test isolation voltage | 4 kV (prim./sec.) |
| Fixing centers a × b × c | 96×60×5.5 mm |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
