In Stock Hot Product
86327
86327 MURRELEKTRONIK MST single-phase safety transformer P: 400VA IN: 230/400VAC OUT: 24VAC
$0.00USD
3152 in stock
Key Specifications
EAN:4048879078603
eClass:27031302
Frequency:50...60 Hz
Standards:EN 61558-1, EN 61558-2-6, EN 62041 category 0
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879078603 |
| eClass | 27031302 |
| Frequency | 50...60 Hz |
| Standards | EN 61558-1, EN 61558-2-6, EN 62041 category 0 |
| Drill hole Ø | 5.8×10 mm |
| Input current | 1.95 A (230 V AC); 1.1 A (400 V AC) |
| Input voltage | 230/400 V AC |
| Output rating | 400 VA |
| Inrush current | 52.3 A (230 V AC); 30.2 A (400 V AC) |
| Output voltage | 24 V AC (SELV) |
| Packaging unit | 1 |
| Mounting method | Key-hole mounting |
| Temperature range | -20...+40 °C (storage temperature -40...+80 °C) |
| country of origin | CZ |
| Dimensions H×W×D | 104×120×123 mm |
| Short-circuit current | 43 A (230 V AC); 24.9 A (400 V AC) |
| customs tariff number | 85043180 |
| Fixing centers a×b×c | 86.5×90×5.8 mm |
| Test isolation voltage | 4 kV (prim./sec.) |
Product Description
MST 1-PHASE SAFETY TRANSFORMERP: 400VA IN: 230/400VAC OUT: 24VAC
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
