In Stock Hot Product
7050-40021-7260400
7050-40021-7260400 MURRELEKTRONIK MQ12 male 0° / MQ12 female 0° PVC 4X0.34 black UL/CSA 4m
$0.00USD
3315 in stock
Key Specifications
EAN:4048879301190
Form:40021
eClass:27279218
Weight::0.159 kg
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879301190 |
| Form | 40021 |
| eClass | 27279218 |
| Weight: | 0.159 kg |
| Art.No.: | 7050-40021-7260400 |
| Outer Ø | 5.0 mm ±5% |
| Protection | IP65 and IP67 when plugged and screwed down (EN 60529) |
| Cable number | 726 |
| Jacket Color | black |
| Packaging unit | 1 |
| Wire isolation | PVC (br, wh, bl, bk) |
| Diameter (core) | 4 × 0.34 mm² |
| Approval (cable) | UL (AWM-Style 2464/1731), CSA |
| Locking of ports | Quick connection, 1/4 turn |
| Material (jacket) | PVC (UL/CSA) |
| Operating voltage | max. 250 V AC/DC |
| Temperature range | -25...+85 °C, depending on cable quality |
| country of origin | DE |
| Bend radius (fixed) | 10 × outer Ø |
| Rated surge voltage | 2.5 kV |
| Bend radius (moving) | 15 × outer Ø |
| No./diameter of wires | 4 × 0.34 mm² |
| customs tariff number | 85444290 |
| Temperature range (fixed) | -30...+80 °C |
| Temperature range (mobile) | -5...+70 °C |
| Operating current per contact | max. 4 A |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
