In Stock Hot Product
7050-12081-6330300
7050-12081-6330300 MURRELEKTRONIK MQ12 male 90° with cable PUR 3X0.34 black UL/CSA, drag chain 3m
$0.00USD
4030 in stock
Key Specifications
AWG:similar to AWG 22
EAN:4048879107426
Form:12081
Coding:A-coded
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| AWG | similar to AWG 22 |
| EAN | 4048879107426 |
| Form | 12081 |
| Coding | A-coded |
| Shield | no |
| eClass | 27279218 |
| Art.No.: | 7050-12081-6330300 |
| Outer Ø | 4.1 mm ±5% |
| Cable Type | 3 (PUR) |
| Protection | IP65/IP67 inserted and tightened (EN 60529) |
| Jacket Color | black |
| No. of poles | 3 |
| Test voltage | 2 500 V AC |
| Torsion speed | 35 cycles per min |
| Color (jacket) | black |
| Material group | IEC 60664-1, category II |
| Packaging unit | 1 |
| Torsion stress | ±180°/m |
| Wire isolation | PP (br, bl, bk) |
| Diameter (core) | 3 × 0.34 mm² |
| Material (wire) | Cu wire, bare |
| Nominal voltage | 300 V AC |
| Resistor (core) | max. 57 Ω/km (20 °C) |
| Approval (cable) | cRUus (AWM-Style 20549/10493); CE conform |
| Locking of ports | Quick connection, 1/4 turn |
| Pollution Degree | 3 |
| Compression gland | PA |
| Material (jacket) | PUR (UL/CSA) |
| Operating voltage | max. 250 V AC/DC |
| Outer-Ø (jacket) | 4.1 mm ±5% |
| Temperature range | -25...+85 °C, depending on cable quality |
| country of origin | DE |
| C-track properties | 10 Mio. |
| Cable weight [g/m] | 29,70 |
| thermal resistance | flame retardant UL 1581 VW1 / CSA FT1 / IEC 60332-1, IEC 60332-2-2 |
| Bend radius (fixed) | 5 × outer Ø |
| Construction (core) | 42 × 0.1 mm (multi-strand wire class 6) |
| Rated surge voltage | 2.5 kV |
| chemical resistance | good resistance to oil, gasoline and chemicals (EN 60811-404) |
| Alternative product: | Product ComparisonMale 90°MQ12, 3-polewith cable sleevesFurther cable lengths on request. Plastic housings with good resistance against chemicals and oils. The resistance to aggressive media should be individually tested for your application. Further details on request.FormForm12081CablesNo./diameter of wires3 × 0.34 mm²Wire isolationPP (br, bl, bk)C-track properties10 Mio.Material (jacket)PUR (UL/CSA)Outer Ø4.1 mm ±5%Bend radius (moving)10 × outer ØTemperature range (fixed)-40...+80 °CTemperature range (mobile)-25...+80 °CCable identification633Cable Type3 (PUR)Approval (cable)cRUus (AWM-Style 20549/10493); CE conformCable weight [g/m]29,70Material (wire)Cu wire, bareResistor (core)max. 57 Ω/km (20 °C)Single wire Ø (core)0.1 mmConstruction (core)42 × 0.1 mm (multi-strand wire class 6)Diameter (core)3 × 0.34 mm²AWGsimilar to AWG 22Material (wire isolation)PPMaterial property (wire isolation)CFC-, halogen-, cadmium-, silicone- and lead-freeShore hardness (wire isolation)70 ±5 DWire-Ø incl. isolation1.25 mm ±5%Color/numbering of wiresbr, bk, blStranding combination3 wires twistedShieldnoMaterial (jacket)PURMaterial property (jacket)CFC-, halogen-, cadmium-, silicone- and lead-free, matt, low-adhesion, machine easy to process, abrasion-resistant, hydrolysis and microbial resistantShore hardness (jacket)90 ±5 AOuter-Ø (jacket)4.1 mm ±5%Color (jacket)blackchemical resistancegood resistance to oil, gasoline and chemicals (EN 60811-404)thermal resistanceflame retardant UL 1581 VW1 / CSA FT1 / IEC 60332-1, IEC 60332-2-2Nominal voltage300 V ACTest voltage2 500 V ACCurrent load capacityto DIN VDE 0298-4Temperature range (fixed)-40...+80 °C, (+90 °C at max. 10 000 operating hours)Temperature range (mobile)-25...+80 °C, (+90 °C at max. 10 000 operating hours)Bend radius (fixed)5 × outer ØBend radius (moving)10 × outer ØNo. of bending cycles (C-track)max. 10 Mio. (25 °C)Travel speed (C-track)max. 3 m/sAcceleration (C-track)max. 10 m/s²Torsion stress±180°/mNo. of torsion cyclesmax. 2 Mio. (25 °C)Torsion speed35 cycles per minJacket ColorblackTechnical DataOperating voltagemax. 250 V AC/DCRated surge voltage2.5 kVOperating current per contactmax. 4 ANo. of poles3Material groupIEC 60664-1, category IICodingA-codedLocking of portsQuick connection, 1/4 turnCompression glandPAProtectionIP65/IP67 inserted and tightened (EN 60529)suitable for corrugated tube (internal Ø)10 mmGeneral dataPollution Degree3Stripping length (jacket)20 mmTemperature range-25...+85 °C, depending on cable qualityCommercial datacountry of originDEcustoms tariff number85444290EAN4048879107426eClass27279218Packaging unit1 |
| Bend radius (moving) | 10 × outer Ø |
| Cable identification | 633 |
| Current load capacity | to DIN VDE 0298-4 |
| No. of torsion cycles | max. 2 Mio. (25 °C) |
| No./diameter of wires | 3 × 0.34 mm² |
| Single wire Ø (core) | 0.1 mm |
| Stranding combination | 3 wires twisted |
| customs tariff number | 85444290 |
| Acceleration (C-track) | max. 10 m/s² |
| Travel speed (C-track) | max. 3 m/s |
| Shore hardness (jacket) | 90 ±5 A |
| Wire-Ø incl. isolation | 1.25 mm ±5% |
| Color/numbering of wires | br, bk, bl |
| Material (wire isolation) | PP |
| Stripping length (jacket) | 20 mm |
| Temperature range (fixed) | -40...+80 °C |
| Material property (jacket) | CFC-, halogen-, cadmium-, silicone- and lead-free, matt, low-adhesion, machine easy to process, abrasion-resistant, hydrolysis and microbial resistant |
| Temperature range (mobile) | -25...+80 °C |
| Operating current per contact | max. 4 A |
| No. of bending cycles (C-track) | max. 10 Mio. (25 °C) |
| Shore hardness (wire isolation) | 70 ±5 D |
| Material property (wire isolation) | CFC-, halogen-, cadmium-, silicone- and lead-free |
| suitable for corrugated tube (internal Ø) | 10 mm |
Product Description
MQ12 male 90° A-cod. with cablePUR 3x0.34 bk UL/CSA+drag ch. 3m
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
