7024-12901-0000000
7024-12901-0000000 MURRELEKTRONIK M12 male 90° wireable scew trerm. F&B PRO 5-pol. max.1,0mm² 3,5-6mm
$0.00USD
4227 in stock
Key Specifications
EAN:4048879804608
eClass:27279221
Material:PA
Protection:IP65, IP68, IP69K inserted and tightened (EN 60529)
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879804608 |
| eClass | 27279221 |
| Material | PA |
| Protection | IP65, IP68, IP69K inserted and tightened (EN 60529) |
| Safety class | II |
| Packaging unit | 1 |
| Locking material | Stainless steel |
| Locking of ports | Screw thread (M12×1 mm) recommended torque 0.6 Nm |
| Compression gland | M12 (SW19) |
| Material (gasket) | EPDM |
| Operating voltage | max. 250 V AC/300 V DC |
| Temperature range | -25...+100 °C |
| country of origin | DE |
| customs tariff number | 85366990 |
| Connection cross section | 0.25...1.0 mm² |
| Sealing range (cable Ø) | 3.5...6.0 mm |
| Operating current per contact | max. 4 A |
Product Description
M12 female 0° A-cod. screw terminal F&B Pro4-pol., 0,25 - 1,0mm², 3,5 - 6mm
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
