7000-P6295-9450050
7000-P6295-9450050 MURRELEKTRONIK M12 Power S-coded female receptacle rear mount wires PUR 4x1.5 0,5m
$0.00USD
3943 in stock
Key Specifications
Form:P6295
Coding:S-coded
Shield:no
Housing:Brass, nickel plated
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Form | P6295 |
| Coding | S-coded |
| Shield | no |
| Housing | Brass, nickel plated |
| Standards | IEC 61076-2-111 |
| Protection | IP65, IP67 mounted and tightened |
| LED display | no |
| Cable length | 0,5 m |
| Mounting set | Screw thread (M16×1.5 mm) mounting nut |
| No. of poles | 4 |
| Material group | IEC 60664-1, category I |
| Material (wire) | Cu wire, tin plated |
| Resistor (core) | max. 13.3 Ω/km (20 °C) |
| Locking material | Brass, nickel plated |
| Locking of ports | Screw thread (M12×1 mm) recommended torque 0.6 Nm |
| Pollution Degree | 3 |
| Compression gland | Flange (SW17) |
| Material (gasket) | FKM |
| Operating voltage | max. 600 V AC |
| Temperature range | -25...+85 °C, depending on cable quality |
| Rated surge voltage | 1.5 kV |
| Cable identification | 945 |
| Wire-Ø incl. isolation | 2.4 mm ±5% |
| Color/numbering of wires | br, wh, bl, gnye vertically striped |
| Material (wire isolation) | PUR |
| Temperature range (fixed) | -40...+90 °C |
| Temperature range (mobile) | -25...+90 °C |
| Operating current per contact | max. 12 A |
| Product article number of manufacturer | 7000-P6295-9450050 |
| suitable for corrugated tube (internal Ø) | without |
Product Description
M12 Power female recept. S-cod. rear
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
