7000-P4231-P080300
7000-P4231-P080300 MURRELEKTRONIK M12 Power L-coded 5pol. female 90° with cable
$0.00USD
4939 in stock
Key Specifications
AWG:similar to AWG 16
EAN:Four trillion forty eight billion eight hundred seventy nine million seven hundred forty thousand seven hundred seventy seven
Form:P4231
eClass:Twenty seven million two hundred seventy nine thousand two hundred eighteen
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| AWG | similar to AWG 16 |
| EAN | Four trillion forty eight billion eight hundred seventy nine million seven hundred forty thousand seven hundred seventy seven |
| Form | P4231 |
| eClass | Twenty seven million two hundred seventy nine thousand two hundred eighteen |
| Weight: | 0.429 kg |
| Article: | 7000-P4231-P080300 |
| Encoding | Coded L |
| Material | PUR |
| Shielded | not |
| Standards | IEC 61076-2-111 |
| Drag chain | 5 Mio. |
| Mount mode | inserted, tight |
| Protection | IP65 and IP67 in state plugged and screwed down (en 60529) |
| Cable gland | M12 (SW17) |
| Packing unit | One |
| Speed torque | 35 cycles per minute |
| Voltage test | 10 kV |
| Color (cover) | grey |
| Rated voltage | 1 000 V AC |
| Type of cable | 3 (PUR) |
| Scrolling speed | max. 3.3 m/s |
| Diameter (cable) | 5 × 1.5 mm2 |
| Material (cable) | Cable, Cu, bare |
| Material (cover) | PUR (UL/CSA) |
| Torsional stress | ±180°/m |
| Blocking Material | Zinc alloy, matt nickel-plated |
| Country of origin | OF |
| Operating voltage | max. 63 V AC/DC |
| Outer Ø of cable | 8.7 mm ±5% |
| Temperature range | -25...+85 °C, depending on the type of cable |
| resistance (main) | max. 13.3 Ω/km (20 °C) |
| Color of the cover | grey |
| Weight cable [G/m] | 129,80 |
| Ø outside (cover) | 8.7 mm ±5% |
| Closure of pathways | Screw M12 × 1 mm (recommended torque 0.6 Nm) self-insurance |
| Degree of pollution | Three |
| Fabriación (cable) | 84 × 0.15 mm (wire multi-core class 6) |
| bend radius (fixed) | 7.5 × outer Ø |
| chemical resistance | good resistance to oils, gasoline and chemicals (IN 60811-404) |
| Bend radius (mobile) | 10 × outer Ø |
| N°/diameter of wire | 5 × 1.5 mm2 |
| Tariff number tariff | Eighty five million four hundred forty four thousand two hundred ninety |
| Combination of torque | 5 strands twisted around a filling central |
| Type approval (cable) | cRUus (AWM-Style 21223/10492) |
| Shore hardness (cover) | 90 ±5 To |
| Identification of cable | P08 |
| Insulation of the cable | PP (br, wh, bl, bk, gr, num) |
| Load current capability | to DIN VDE 0298-4 |
| Cable-Ø incl. Isolation | 2.3 mm ±5% |
| Acceleration (drag chain) | max. 5 m/s2 |
| Color/numbering of cables | ne, az, bl, ma, gr, num |
| Temperature range (fixed) | -50...+80 °C |
| Number of cycles of torque | max. 2 Mio. (25 °C) |
| Temperature range (mobile) | -20...+80 °C |
| Material (insulation cable) | PP |
| Working current per contact | max. 16 To |
| Length of desforrado (cover) | 100 mm |
| Single-line diagram Ø (main) | 0.15 mm |
| Distance of travel (drag chain) | max. 5 m (horizontal) |
| Resistance shore (wire insulation) | 60 ±5 D |
| Number of bending cycles (drag chain) | max. 5 Mio. (25 °C) |
| suitable for corrugated tube (Ø int.) | 12 mm |
| Characteristics of the material (cover) | CFC-free, halogen-free, and cadmium, silicon and lead, matte, low adhesion, easy to process in the machine, resistant to abrasion, hydrolysis and microbes |
| Properties of the material (wire insulation) | CFC-free, halogen-free, and cadmium, silicon and lead |
Product Description
M12 Power female 90° L-cod. with cablePUR 5x1.5 gy UL/CSA+drag ch. 3m
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
