In Stock Hot Product
7000-C0504-7620000
7000-C0504-7620000 MURRELEKTRONIK Cable drum Ø 500MM PUR 4x0.75 shielded black 400m
$0.00USD
3193 in stock
Key Specifications
:min. 85%
AWG:similar to AWG 18
EAN:4048879757058
Shield:yes
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| min. 85% | |
| AWG | similar to AWG 18 |
| EAN | 4048879757058 |
| Shield | yes |
| eClass | 27062011 |
| Weight: | 35.124 kg |
| Art.No.: | 7000-C0504-7620000 |
| Test voltage | 2 000 V AC |
| Color (jacket) | black |
| Packaging unit | 1 |
| Diameter (core) | 4 × 0.75 mm² |
| Material (wire) | Cu wire, bare |
| Nominal voltage | 240 V AC |
| Resistor (core) | max. 26 Ω/km (20 °C) |
| Approval (cable) | CE |
| Material (jacket) | PUR |
| Outer-Ø (jacket) | 6.6 mm ±5% |
| country of origin | IT |
| Cable weight [g/m] | 80,3 |
| thermal resistance | flame retardant |
| Bend radius (fixed) | 14 × outer Ø |
| Construction (core) | 24 × 0.2 mm (multi-strand wire class 5) |
| chemical resistance | good resistance to oil, gasoline and chemicals |
| Bend radius (moving) | 20 × outer Ø |
| Cable identification | 762 |
| Current load capacity | to DIN VDE 0298-4 |
| Single wire Ø (core) | 0.2 mm |
| Stranding combination | 4 wires twisted |
| customs tariff number | 85444995 |
| Shore hardness (jacket) | 85 ±5 A |
| Wire-Ø incl. isolation | 1.8 mm ±5% |
| Color/numbering of wires | br, bk, bl, wh, num |
| Material (wire isolation) | PE |
| Temperature range (fixed) | -40...+80 °C |
| Material property (jacket) | CFC-, halogen-, cadmium-, silicone- and lead-free, matt, low-adhesion, machine easy to process, abrasion-resistant, hydrolysis and microbial resistant |
| Temperature range (mobile) | -5...+50 °C |
| Shore hardness (wire isolation) | 60 ±5 D |
| Material property (wire isolation) | CFC-, halogen-, cadmium-, silicone- and lead-free |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
