7000-C0201-3350000
7000-C0201-3350000 MURRELEKTRONIK Cable drum Ø 355MM PUR 4X0.34 shielded gray, UL/CSA 100m
$0.00USD
3441 in stock
Key Specifications
EAN:4048879385060
Shield:yes
eClass:27062011
Outer Ø:5.9 mm ±5%
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879385060 |
| Shield | yes |
| eClass | 27062011 |
| Outer Ø | 5.9 mm ±5% |
| Cable Type | PUR-OB |
| Jacket Color | gray |
| Test voltage | 2000 V AC |
| Color (jacket) | gray |
| Packaging unit | 1 |
| Wire isolation | PP (br, wh, bl, bk) |
| Diameter (core) | 4× 0.34 mm² |
| Material (wire) | Cu wire, bare |
| Nominal voltage | 300 V AC |
| Resistor (core) | max. 52 Ω/km (20 °C) |
| Approval (cable) | UL (AWM-Style 20233/1992), CSA; CE conform |
| Material (jacket) | PUR (UL/CSA) |
| Outer-Ø (jacket) | 5.9 mm ±5% |
| country of origin | IT |
| Cable weight [g/m] | 56,10 |
| thermal resistance | flame retardant UL VW1, CSA FT1 |
| Bend radius (fixed) | 10× outer Ø |
| chemical resistance | good resistance to oil, gasoline and chemicals (VDE 0472 Teil 803 Test B) |
| Bend radius (moving) | 10× outer Ø |
| Cable identification | 335 |
| optical shield cover | min. 85% |
| No./diameter of wires | 4× 0.34 mm² |
| Single wire Ø (core) | 0.1 mm |
| Stranding combination | 4 wires twisted |
| customs tariff number | 85444995 |
| Shore hardness (jacket) | 85 ±3 A |
| Wire-Ø incl. isolation | 1.55 mm ±5% |
| Color/numbering of wires | br, bk, bl, wh |
| Material (wire isolation) | PP |
| Temperature range (fixed) | -40...+80 °C |
| Temperature range (mobile) | -20...+80 °C |
| Shore hardness (wire isolation) | 72 ±3 D |
| Material property (wire isolation) | CFC-, halogen-, cadmium-, silicone- and lead-free |
Product Description
CABLE DRUM Ø 355MM
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
