7000-40521-7331000
7000-40521-7331000 MURRELEKTRONIK M12 male 0° / M12 female 0° PUR 5x0.34 shielded black UL/CSA 10m
$0.00USD
3543 in stock
Key Specifications
AWG:similar to AWG 22
EAN:4048879410533
Form:40521
Coding:A-coded
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| AWG | similar to AWG 22 |
| EAN | 4048879410533 |
| Form | 40521 |
| Coding | A-coded |
| Shield | yes |
| eClass | 27279218 |
| Art.No.: | 7000-40521-7331000 |
| Material | PUR |
| Outer Ø | 6.3 ±0.2 mm |
| Standards | DIN EN 61076-2-101 (M12) |
| Protection | IP65 and IP67 when plugged and screwed down (EN 60529) |
| LED display | no |
| Cable number | 733 |
| Jacket Color | black |
| No. of poles | 5 |
| Test voltage | 2 000 V AC |
| Color (jacket) | black |
| Material group | IEC 60664-1, category I |
| Packaging unit | 1 |
| Wire isolation | PP (br, wh, bl, bk, gr) |
| Diameter (core) | 5 × 0.34 mm² |
| Material (wire) | Cu wire, bare |
| Mounting method | inserted, tightened |
| Nominal voltage | 300 V AC |
| Resistor (core) | max. 57 Ω/km (20 °C) |
| Approval (cable) | UL (AWM-Style 20549/10493), CSA |
| Locking material | Zinc die casting, matte nickel plated |
| Locking of ports | Screw thread M12 × 1 mm (recommended torque 0.6 Nm) self-securing |
| Pollution Degree | 3 |
| Compression gland | M12 (SW13) |
| Material (gasket) | FKM |
| Material (jacket) | PUR (UL/CSA) |
| Operating voltage | max. 60 V AC/DC |
| Outer-Ø (jacket) | 6.3 ±0.2 mm |
| Temperature range | -25...+85 °C, depending on cable quality |
| country of origin | CZ |
| Material (contact) | Copper alloy |
| Bend radius (fixed) | 10 × outer Ø |
| Construction (core) | 42 × 0.1 mm (multi-strand wire class 6) |
| Rated surge voltage | 1.5 kV |
| chemical resistance | good resistance to oil, gasoline and chemicals (VDE 0472 Teil 803 Test B) |
| Alternative product: | Product ComparisonMale straight – female straightM12 – M12, 5-poleA-codedshieldedPlastic housings with good resistance against chemicals and oils. The resistance to aggressive media should be individually tested for your application. Further details on request. Further cable lengths on request.FormForm40521CablesCable number733No./diameter of wires5 × 0.34 mm²Wire isolationPP (br, wh, bl, bk, gr)Jacket ColorblackMaterial (jacket)PUR (UL/CSA)Outer Ø6.3 ±0.2 mmBend radius (moving)15 × outer ØTemperature range (fixed)-50...+80 °CTemperature range (mobile)-25...+80 °CApproval (cable)UL (AWM-Style 20549/10493), CSAMaterial (wire)Cu wire, bareResistor (core)max. 57 Ω/km (20 °C)Single wire Ø (core)0.1 mmConstruction (core)42 × 0.1 mm (multi-strand wire class 6)Diameter (core)5 × 0.34 mm²AWGsimilar to AWG 22Material (wire isolation)PPMaterial property (wire isolation)CFC-, halogen-, cadmium-, silicone- and lead-freeShore hardness (wire isolation)74 ±5 DWire-Ø incl. isolation1.5 mm ±5%Color/numbering of wiresbr, bk, bl, wh, grStranding combination5 wires twisted around central fillerShieldyesMaterial (jacket)PURShore hardness (jacket)89 ±5 AOuter-Ø (jacket)6.3 ±0.2 mmColor (jacket)blackchemical resistancegood resistance to oil, gasoline and chemicals (VDE 0472 Teil 803 Test B)Nominal voltage300 V ACTest voltage2 000 V ACCurrent load capacityto DIN VDE 0298-4Bend radius (fixed)10 × outer ØTechnical DataOperating voltagemax. 60 V AC/DCOperating voltage (only UL listed)30 V AC/DCRated surge voltage1.5 kVOperating current per contactmax. 4 ANo. of poles5Material groupIEC 60664-1, category ICodingA-codedLED displaynoLocking of portsScrew thread M12 × 1 mm (recommended torque 0.6 Nm) self-securingCompression glandM12 (SW13)ProtectionIP65 and IP67 when plugged and screwed down (EN 60529)Locking materialZinc die casting, matte nickel platedMaterialPURsuitable for corrugated tube (internal Ø)withoutGeneral dataStandardsDIN EN 61076-2-101 (M12)Mounting methodinserted, tightenedMaterial (contact)Copper alloyMaterial (contact surface)AuMaterial (gasket)FKMPollution Degree3Temperature range-25...+85 °C, depending on cable qualityCommercial datacountry of originCZcustoms tariff number85444290EAN4048879410533eClass27279218Packaging unit1 |
| Bend radius (moving) | 15 × outer Ø |
| Current load capacity | to DIN VDE 0298-4 |
| No./diameter of wires | 5 × 0.34 mm² |
| Single wire Ø (core) | 0.1 mm |
| Stranding combination | 5 wires twisted around central filler |
| customs tariff number | 85444290 |
| Shore hardness (jacket) | 89 ±5 A |
| Wire-Ø incl. isolation | 1.5 mm ±5% |
| Color/numbering of wires | br, bk, bl, wh, gr |
| Material (wire isolation) | PP |
| Temperature range (fixed) | -50...+80 °C |
| Material (contact surface) | Au |
| Temperature range (mobile) | -25...+80 °C |
| Operating current per contact | max. 4 A |
| Shore hardness (wire isolation) | 74 ±5 D |
| Material property (wire isolation) | CFC-, halogen-, cadmium-, silicone- and lead-free |
| Operating voltage (only UL listed) | 30 V AC/DC |
| suitable for corrugated tube (internal Ø) | without |
