In Stock Hot Product
7000-13014-0000000
7000-13014-0000000 MURRELEKTRONIK M12 female 0° self wireable screw term. 4-pol. 0,14 1,5mm², 2,5-8mm cable ..
$0.00USD
4915 in stock
Key Specifications
EAN:4048879838894
eClass:27279221
Protection:IP67 mounted and tightened
Mating cycles:≥ 100
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879838894 |
| eClass | 27279221 |
| Protection | IP67 mounted and tightened |
| Mating cycles | ≥ 100 |
| Packaging unit | 1 |
| Locking of ports | Screw thread (M12×1 mm) recommended torque 0.6 Nm |
| Pollution Degree | 3/2 |
| Operating voltage | max. 250 V AC/DC |
| Temperature range | -30...+85 °C |
| country of origin | CZ |
| Dimensions H×W×D | 42×28,5×20 mm |
| Isolation resistance | ≥ 100 MΩ |
| customs tariff number | 85366990 |
| Connection cross section | 0.14...1.5 mm² |
| Sealing range (cable Ø) | 2.5...8.0 mm |
| Operating current per contact | max. 7.5 A (+40 °C; 1.5 mm²) |
Product Description
M12 female 90° A-cod. screw terminal4-pol., 0,14 - 1,5mm², 2,5 - 8mm
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
