7000-08951-6951000
7000-08951-6951000 MURRELEKTRONIK M8 female 90° with cable PUR 5x0.25 black UL 10m
$0.00USD
3734 in stock
Key Specifications
AWG:similar to AWG 24
EAN:4048879731669
Form:08951
Coding:B-coded
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| AWG | similar to AWG 24 |
| EAN | 4048879731669 |
| Form | 08951 |
| Coding | B-coded |
| Shield | no |
| eClass | 27279218 |
| Weight: | 0.13 kg |
| Art.No.: | 7000-08951-6951000 |
| Material | TPU |
| Protection | IP67 inserted and tightened (EN 60529) |
| LED display | no |
| Jacket Color | black |
| No. of poles | 5 |
| Test voltage | 3 000 V AC |
| Mating cycles | ≥ 100 |
| Color (jacket) | black |
| Packaging unit | 1 |
| Diameter (core) | 5 × 0.25 mm² |
| Material (wire) | Cu wire, bare |
| Mounting method | inserted, tightened |
| Nominal voltage | 300 V |
| Resistor (core) | max. 58 Ω/km (20 °C) |
| Locking material | Zinc die casting, matte nickel plated |
| Locking of ports | Screw thread M8 × 1 mm (recommended torque 0.4 Nm) self-securing |
| Pollution Degree | 3/2 |
| Compression gland | M8 (SW9) |
| Material (gasket) | FPM |
| Material (jacket) | PUR |
| Operating voltage | max. 30 V AC/DC |
| Outer-Ø (jacket) | 4.7 mm ±5% |
| Temperature range | -30...+80 °C |
| country of origin | CZ |
| Material (contact) | Copper alloy |
| Construction (core) | 32 × 0.1 mm (multi-strand wire class 6) |
| Bend radius (moving) | 7.5 × outer Ø |
| Cable identification | 695 |
| Single wire Ø (core) | 0.1 mm |
| Stranding combination | 5 wires twisted around central filler |
| customs tariff number | 85444290 |
| Acceleration (C-track) | max. 5 m/s² |
| Travel speed (C-track) | max. 3 m/s |
| Wire-Ø incl. isolation | 1.2 mm ±5% |
| Material (wire isolation) | PP |
| Temperature range (fixed) | -25...+80 °C |
| Material (contact surface) | Au |
| Operating current per contact | max. 3 A |
| No. of bending cycles (C-track) | max. 5 Mio. (25 °C) |
