7000-08561-9710050
7000-08561-9710050 MURRELEKTRONIK M8 MALE FLANGE PLUG 1-2-3-4 Wire 4x0.25 0.5m
$0.00USD
3755 in stock
Key Specifications
Form:08561
Outer Ø:1.3 mm ±5%
Standards:DIN EN 61076-2-104 (M8)
Protection:IP67
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Form | 08561 |
| Outer Ø | 1.3 mm ±5% |
| Standards | DIN EN 61076-2-104 (M8) |
| Protection | IP67 |
| Cable length | 0,5 m |
| Cable number | 971 |
| Material group | IEC 60664-1, category I |
| Wire isolation | PUR |
| Locking of ports | Screw thread (M8×1 mm) recommended torque 0.4 Nm, self-securing |
| Operating voltage | max. 50 V AC/60 V DC |
| Temperature range | -40...+85 °C |
| Material (contact) | Brass, gold plated |
| Bend radius (fixed) | 5× outer Ø |
| Rated surge voltage | 0.8 kV |
| No./diameter of wires | 4× 0.34 mm² |
| Over voltage category | II |
| Temperature range (fixed) | -40...+90 °C |
| Temperature range (mobile) | -25...+90 °C |
| Operating current per contact | max. 4 A |
| Product article number of manufacturer | 7000-08561-9710050 |
Product Description
M8 MALE FLANGE PLUG 1-2-3-4
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
