In Stock Hot Product
69004
69004 MURRELEKTRONIK Emergency stop with 2 positive opening
$0.00USD
4908 in stock
Key Specifications
EAN:4048879663359
B10d:250 000
PIN 1:N/C 1
PIN 2:N/C 1
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879663359 |
| B10d | 250 000 |
| PIN 1 | N/C 1 |
| PIN 2 | N/C 1 |
| PIN 3 | N/C 2 |
| PIN 4 | N/C 2 |
| PIN 5 | N/O 1 |
| PIN 6 | N/O 1 |
| PIN 7 | (X2/-) |
| PIN 8 | (X1/+) |
| eClass | 27371244 |
| Weight: | 0.1 kg |
| Art.No.: | 69004 |
| LED Light | max. 30 V AC/DC typ. 4 mA (24 V DC) |
| Connection | M12 (8-pole) |
| Lambda (d) | 20% (N/C) |
| Protection | IP65 |
| Packaging unit | 1 |
| Mounting method | with clip on back |
| Operating current | 1.5 A |
| Operating voltage | 1...36 V DC (UL: 30 V DC) |
| Temperature range | -25...+70 °C (storage temperature -25...+85 °C) |
| country of origin | DE |
| Material (contact) | Ag Ni |
| Mech./ elect. life | 50 000 actuations, load-temperature dependent |
| Contact bounce time | max. 10 ms |
| customs tariff number | 85365080 |
| Dimensions H × W × D | 52×124×42 mm |
Product Description
Emergency stop with 2 positive openingcontacts in a IP65 enclosure
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
