In Stock Hot Product
6686061
6686061 MURRELEKTRONIK MET single-phase control and isolation transformer P: 1500VA IN: 400VAC+/- 5% OUT: 23..
$0.00USD
4380 in stock
Key Specifications
EAN:4048879066334
eClass:27031302
Art.No.::6686061
Frequency:50...60 Hz
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879066334 |
| eClass | 27031302 |
| Art.No.: | 6686061 |
| Frequency | 50...60 Hz |
| Standards | EN 61558-1, EN 61558-2-4, EN 62041 category 0 |
| Drill hole Ø | 7×11 mm |
| Input current | 3.97 A (400 V AC) |
| Input voltage | 400 V AC ±5% |
| Output rating | 1 500 VA |
| Inrush current | 50 A (400 V AC) |
| Output voltage | 230 V AC |
| Packaging unit | 1 |
| Mounting method | Key-hole mounting |
| Temperature range | -20...+60 °C (storage temperature -40...+80 °C) |
| country of origin | CZ |
| Alternative product: | Product ComparisonSingle-phase - Control and Isolation Transformers1 500 VASpring clamp terminalsIsolation class T 60/BInputInput voltage400 V AC ±5%Frequency50...60 HzInput current3.97 A (400 V AC)Short-circuit current201.5 A (400 V AC)Inrush current50 A (400 V AC)General dataStandardsEN 61558-1, EN 61558-2-4, EN 62041 category 0Dimensions H × W × D168×174×162 mmFixing centers a × b × c141.5×135×7 mmDrill hole Ø7×11 mmMounting methodKey-hole mountingTemperature range-20...+60 °C (storage temperature -40...+80 °C)OutputOutput voltage230 V ACOutput rating1 500 VACommercial datacountry of originCZcustoms tariff number85043200EAN4048879066334eClass27031302Packaging unit1 |
| Short-circuit current | 201.5 A (400 V AC) |
| customs tariff number | 85043200 |
| Dimensions H × W × D | 168×174×162 mm |
| Fixing centers a × b × c | 141.5×135×7 mm |
Product Description
MET 1-PHASE CONTROL AND ISOLATION TRANSFORMERP: 1500VA IN: 400VAC+/- 5% OUT: 230VAC
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
