6644334 MURRELEKTRONIK MIRO TEMP. CONVERTER PT100 2 /3-LEAD METHOD
$0.00USD
3710 in stock
Key Specifications
EAN:4048879022347
eClass:27210990
Tolerance:±1% from end value
Packaging unit:1
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879022347 |
| eClass | 27210990 |
| Tolerance | ±1% from end value |
| Packaging unit | 1 |
| Mounting method | DIN-rail mountable (EN 60715) |
| Operating current | max. 80 mA |
| Operating voltage | 24 V DC (18...30 V DC), smoothed |
| Temperature range | 0...+60 °C |
| country of origin | CZ |
| Dimensions H×W×D | 90×12.4×70 mm |
| customs tariff number | 85437090 |
| Functional description | The Murrelektronik temperature converter module works in conjunction with a temperature sensor PT100 (IEC 751/EN 60751) and converts the temperature into a standard signal format of (0...10 V, 4...20 mA, 0...20 mA). The MTW modules supply a constant curre |
| Output signals at 0...20 mA | max. 500 Ω RL |
| Output signals at 0...10 V DC | max. 25 mA, overload protected |
| Output signals at 4...20 V mA | max. 500 Ω RL |
| Cable resistance (without Pt100) | max. 100 Ω (3-wire technology) |
Product Description
MIRO TEMP. CONVERTER PT100 - 2 /3-LEAD METHODIN: 0°C..+200°C - OUT:0..10 V / (0)4..20 mA
