In Stock Hot Product
6644207
6644207 MURRELEKTRONIK MMW ANALOG COUPLER COMPONENT
$0.00USD
3376 in stock
Key Specifications
EAN:4048879022491
Load:approx. 75 Ω
eClass:27210990
Input current:0...20 mA, 4...20 mA
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879022491 |
| Load | approx. 75 Ω |
| eClass | 27210990 |
| Input current | 0...20 mA, 4...20 mA |
| Input voltage | 0...5, 0...10, ±10 V DC |
| Input resistor | approx. 100 kΩ |
| Packaging unit | 1 |
| Mounting method | DIN-rail mountable (EN 60715) |
| Temperature range | -25...+50 °C |
| country of origin | CZ |
| Dimensions H×W×D | 80×6.2×70 mm |
| customs tariff number | 85437090 |
| Functional description | Due to an integrated current limiter on the output, the output is short circuit and overload protected. A special characteristic of the MULTI Converter Art.-No. 6644207 includes: Analog voltage signals 0...5 V/0...10 V and -10…+10 V and current signals 0. |
| Test isolation voltage | 0.75 kV |
Product Description
MMW ANALOG COUPLER COMPONENTIN:-10..+10V/(0)4..20 mA - OUT:0..10V/(0)4..20 mA
