In Stock Hot Product
61358
61358 MURRELEKTRONIK RELAIS 230V AC-1U
$0.00USD
3883 in stock
Key Specifications
EAN:4048879025799
eClass:27371001
Art.No.::61358
Max. power (W):max. 1.6 VA/0.65 W
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879025799 |
| eClass | 27371001 |
| Art.No.: | 61358 |
| Max. power (W) | max. 1.6 VA/0.65 W |
| Packaging unit | 1 |
| Switching time | 15/20 ms |
| Min. load current | 100 mA (12 V DC) |
| Switching current | max. 16 A |
| Switching voltage | max. 250 V AC/DC |
| country of origin | IT |
| Material (contact) | Ag Sn O2 |
| Alternative product: | Product Comparison1 NO/NC contact230 V ACTechnical DataSwitching voltagemax. 250 V AC/DCSwitching currentmax. 16 APower rating (voltage dependent)max. 4 000 VA/300 WMin. load current100 mA (12 V DC)Max. power (W)max. 1.6 VA/0.65 WSwitching time15/20 msGeneral dataDimensions H × W × D25×29×12.4 mmMaterial (contact)Ag Sn O2Commercial datacountry of originITcustoms tariff number85364900EAN4048879025799eClass27371001Packaging unit1 |
| customs tariff number | 85364900 |
| Dimensions H × W × D | 25×29×12.4 mm |
| Power rating (voltage dependent) | max. 4 000 VA/300 W |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
