5TT4468-2
5TT4468-2 SIEMENS Remote control switch Contact for 40 A Voltage 24 V AC 2 change-over contacts
$0.00USD
4047 in stock
Key Specifications
:
EAN:4001869521091
UPC:Not available
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4001869521091 |
| UPC | Not available |
| ETIM | 5 |
| depth | 73 mm |
| width | 70 mm |
| eClass | 6 |
| height | 90 mm |
| Group Code | P310 |
| net weight | 290 g |
| ● maximum | 25 mm² |
| ● minimum | 2.5 mm² |
| Confirmation | |
| Metal Factor | None |
| Date5/11/2022 | |
| Product Group | 5528 |
| Product class | B: return restricted, please contact your Siemens partner/contact |
| Quantity Unit | 1 Piece |
| Commodity Code | 85362010 |
| Product family | SENTRON 5TT4 Remote Control Switches |
| power loss [W] | |
| supply voltage | 400 V |
| Net Weight (kg) | 0,404 Kg |
| control voltage | |
| mounting height | 90 mm |
| type of voltage | |
| ● rated value | 40 A |
| fastening method | DIN rail |
| Country of origin | Slovenia |
| mounting position | Horizontal and vertical |
| ● _1 / setpoint | 24 V |
| LKZ_FDB/ CatalogID | LV10 |
| Packaging Quantity | 1 |
| installation depth | 73 mm |
| product brand name | SENTRON |
| ● at cos phi 0.6 | 40 A |
| Function (EF000030) | Mechanical switch |
| Packaging Dimension | 35,00 x 90,00 x 73,00 |
| Product Description | Remote control switch Contact for 40 A Voltage 24 V AC 2 change-over contacts |
| number of terminals | 6 |
| product designation | Remote control switch |
| protection class IP | IP20 |
| latching relay design | Mechanical switch |
| number of CO contacts | 2 |
| number of NC contacts | 0 |
| number of NO contacts | 0 |
| ● _1 / initial value | 207 V |
| Product Lifecycle (PLM) | PM300:Active Product |
| General Product Approval | Declaration of Conformity |
| pulse duration / minimum | 50 ms |
| supply voltage / minimum | 230 V |
| ● of control voltage_1 | AC |
| Built-in depth (EF000218) | 73.0 |
| Supply voltage (EF004127) | ['230', '400'] |
| control voltage frequency | |
| ● _1 / full-scale value | 253 V |
| Export Control Regulations | AL : N / ECCN : N |
| Mounting method (EF000003) | DIN rail |
| switching capacity current | |
| Standard lead time ex-works | 4 Day/Days |
| Surcharge for Raw Materials | None |
| Control voltage 1 (EF002952) | ['207', '253'] |
| Control voltage 2 (EF002953) | ['-', '-'] |
| Package size unit of measure | MM |
| number of modular width units | 2 |
| Rated switch current (EF006706) | 40 |
| continuous voltage fuse version | Yes |
| switching capacity apparent power | |
| width of opening / of the contacts | 3 mm |
| product function / direct operation | Yes |
| Manual operation possible (EF005881) | true |
| Type of control voltage 1 (EF002954) | AC |
| Type of control voltage 2 (EF002955) | AC/DC |
| Article Number (Market Facing Number) | 5TT4468-2 |
| Max. load fluorescent lamp (EF004971) | 3654 |
| Frequency control voltage 1 (EF002956) | ['50.0', '60.0'] |
| Frequency control voltage 2 (EF002957) | - |
| Max. incandescent lamp load (EF004952) | 8800 |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| ambient temperature / during operation | |
| surge voltage resistance / rated value | 4 kV |
| electrical endurance (switching cycles) | 50 000 |
| ● at 16 A / per contact / rated value | 3 W |
| Voltage type of supply voltage (EF002991) | AC |
| type of voltage / of the operating voltage | AC |
| ● for uncompensated fluorescent lamp load | 3 654 VA |
| product component / switch position indicator | Yes |
| ● of magnet coil / with pulse / rated value | 12 W |
| Width in number of modular spacings (EF002950) | 2 |
| ● for fluorescent lamp load with DUO circuit | 3 712 VA |
| Max. switching current (cos phi = 0.6) (EF004920) | 40 |
| switching current / at AC / per contact / minimum | 100 mA |
| Max. load fluorescent lamp (Duo circuit) (EF004972) | 3712 |
| Number of contacts as change-over contact (EF008257) | 2 |
| Region Specific PriceGroup / Headquarter Price Group | 12F / 1BK |
| galvanic isolation / between magnet coil and contact | Yes |
| switching voltage / of the contacts / at AC / minimum | 10 V |
| Number of contacts as normally open contact (EF008256) | 0 |
| Number of contacts as normally closed contact (EF008255) | 0 |
| ● for fluorescent lamp load with parallel compensation | 1 798 VA |
| connectable conductor cross-section / for rigid conductor | |
| Max. load fluorescent lamp (parallel compensated) (EF004973) | 1798 |
| switching capacity active power / with incandescent lamp load | 8 800 W |
| power loss [V∙A] / of magnet coil / with pulse / rated value | 26 VA |
| Compliance with the substance restrictions according to RoHS directive | Since: 24.04.2013 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
| connectable conductor cross-section / for flexible conductor / with core end processing | |
| General Product ApprovalDeclaration of ConformityTest CertificatesotherConfirmationUK Declaration of ConformityMiscellaneousMiscellaneousotherConfirmation | General Product Approval |
Product Description
CONTACT BISTABLE RELAY FOR 40 A VOLTAGE AC 24 V 2 SWITCH. Cancelations and returns limited. Consult conditions.
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
