5SM3315-6KK
5SM3315-6KK SIEMENS Residual current operated circuit breaker, 2-pole, type A, In: 125 A, 30 mA, Un AC: 230 V
$0.00USD
3887 in stock
Key Specifications
:
EAN:4001869272726
UPC:Not available
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4001869272726 |
| UPC | Not available |
| ETIM | 5 |
| depth | 70 mm |
| other | Dangerous Good |
| width | 36 mm |
| UNSPSC | 14 |
| eClass | 6 |
| height | 90 mm |
| Group Code | P310 |
| net weight | 265 g |
| ● maximum | 50 mm² |
| ● minimum | 1.5 mm² |
| Confirmation | |
| Metal Factor | L-O----- |
| Date5/17/2022 | |
| Miscellaneous | Transport Information |
| Product Group | 5511 |
| Product class | B: return restricted, please contact your Siemens partner/contact |
| Quantity Unit | 1 Piece |
| Commodity Code | 85362090 |
| Product family | RCCBs |
| Net Weight (kg) | 0,265 Kg |
| number of poles | 2 |
| fastening method | DIN rail (REG) |
| Country of origin | Germany |
| mounting position | any |
| LKZ_FDB/ CatalogID | LV10.1 |
| Packaging Quantity | 1 |
| installation depth | 70 mm |
| product brand name | SENTRON |
| Packaging Dimension | 72,00 x 90,00 x 79,00 |
| Product Description | Residual current operated circuit breaker, 2-pole, type A, In: 125 A, 30 mA, Un AC: 230 V |
| operational current | |
| product designation | RCCB |
| protection class IP | IP20, if the distribution board is installed, with connected conductors |
| Frequency (EF005455) | 50 Hz |
| overvoltage category | III |
| design of the product | Instantaneous |
| residual current type | A |
| Product Lifecycle (PLM) | PM300:Active Product |
| ● at AC / rated value | 125 A |
| ● maximum permissible | 75 °C |
| ● minimum permissible | -40 °C |
| General Product Approval | Declaration of Conformity |
| Rated current (EF000227) | 125 |
| Rated voltage (EF000228) | 230 |
| Built-in depth (EF000218) | 70.0 |
| Export Control Regulations | AL : N / ECCN : N |
| Mounting method (EF000003) | DIN rail |
| Number of poles (EF001391) | 2 |
| switching capacity current | |
| Pollution degree (EF002570) | - |
| Standard lead time ex-works | 10 Day/Days |
| Surcharge for Raw Materials | None |
| Package size unit of measure | MM |
| short-circuit current rating | 10 kA |
| number of modular width units | 2 |
| Rated fault current (EF002358) | 0.03 |
| product feature / silicon-free | Yes |
| Leakage current type (EF002560) | A |
| Selective protection (EF002561) | false |
| position / of power supply cord | top or bottom |
| Surge current capacity (EF002564) | 1.0 |
| With interlocking device (EF007385) | true |
| Degree of protection (IP) (EF005474) | IP20 |
| ambient temperature / during storage | |
| tripping fault current / rated value | 30 mA |
| Article Number (Market Facing Number) | 5SM3315-6KK |
| Rated insulation voltage Ui (EF001366) | - |
| Short-time delayed tripping (EF003604) | false |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| ambient temperature / during operation | |
| surge current resistance / rated value | 1 kA |
| switching function / short-term delayed | No |
| ● according to EN 60898 / rated value | 1.25 kA |
| Additional equipment possible (EF008148) | true |
| value range / of the operating frequency | 50 Hz |
| ● according to IEC 61008-1 / rated value | 1.25 kA |
| connectable conductor cross-section / solid | |
| value range / of the supply voltage / at AC | 230 V |
| tightening torque / with screw-type terminals | |
| value range / of the supply voltage frequency | 50 Hz |
| Width in number of modular spacings (EF002950) | 2 |
| connectable conductor cross-section / stranded | |
| Ambient temperature during operating (EF007515) | ['-25', '45'] |
| Rated impulse withstand voltage Uimp (EF011980) | - |
| Short-circuit breaking capacity (Icw) (EF002562) | 10.0 |
| supply voltage / for testing equipment / minimum | 100 V |
| Region Specific PriceGroup / Headquarter Price Group | 11C / 1AH |
| mechanical service life (switching cycles) / typical | 10 000 |
| size of installation devices / according to DIN 43880 | 1 |
| product extension / installable / supplementary devices | Yes |
| Connectable conductor cross section solid-core (EF007337) | ['1.5', '50.0'] |
| Connectable conductor cross section multi-wired (EF007343) | ['1.5', '50.0'] |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.07.2006 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
| number of test cycles / for environmental testing / according to IEC 60068-2-30 | 28 |
| General Product ApprovalDeclaration of ConformityTest CertificatesConfirmationMiscellaneousMiscellaneousotherDangerous GoodMiscellaneousTransport Information | General Product Approval |
Product Description
Class A differential switch, 2.5 mod., 2-pole, 125 A, 30 mA. Cancelations and returns limited. Consult conditions.
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
