57263 MURRELEKTRONIK CUBE20S ANALOG INPUT MODULE AI4
$0.00USD
3143 in stock
Key Specifications
EAN:4048879423762
eClass:27242601
Weight::0.06 kg
Accuracy:max. ±0.2%
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879423762 |
| eClass | 27242601 |
| Weight: | 0.06 kg |
| Accuracy | max. ±0.2% |
| Art.No.: | 57263 |
| Connection | Differential voltage input |
| Protection | IP20 |
| Input range | -10 V DC...+10 V DC |
| Module supply | via system connection |
| Input resistor | 200 kΩ |
| Packaging unit | 1 |
| Mounting method | DIN-rail mountable (EN 60715) |
| Temperature range | 0...+60 °C (storage temperature -25...+70 °C) |
| country of origin | TH |
| Diagnostic via BUS | per module |
| Diagnostic via LED | per module and channel |
| Current consumption | max. 60 mA from system, max. 25 mA externally (UI) |
| Resolution (analog) | 15 Bit + sign |
| Communication status | via LED |
| customs tariff number | 85389099 |
| Dimensions H × W × D | 109×12.9×76.5 mm |
| Monitoring - no voltage | no |
| Conversion time (analog) | 480 µs (all channels) |
| Monitoring - under voltage | yes |
| Short-circuit and overload | yes |
| Wire break upper/lower limit overload | per module via LED and BUS |
Product Description
CUBE20S ANALOG INPUT MODULE AI4 4X16Bit (U -10…+10V)
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
