In Stock Hot Product
57161
57161 MURRELEKTRONIK CUBE20S COUNTER MODULE
$0.00USD
4524 in stock
Key Specifications
EAN:4048879422949
eClass:27242605
Weight::0.06 kg
Art.No.::57161
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879422949 |
| eClass | 27242605 |
| Weight: | 0.06 kg |
| Art.No.: | 57161 |
| Connection | Spring clamp plug-in terminals: max. 1.5 mm² (AWG 16) |
| Protection | IP20 |
| Counter depth | 32 Bit (31 Bit + sign) |
| Counter input | 1 |
| Module supply | 24 V DC (20.4...28.8 V DC) |
| Packaging unit | 1 |
| Mounting method | DIN-rail mountable (EN 60715) |
| Counter frequency | max. 2 MHz |
| Temperature range | 0...+60 °C (storage temperature -25...+70 °C) |
| country of origin | TH |
| Diagnostic via BUS | per module |
| Diagnostic via LED | per module |
| Current consumption | max. 70 mA |
| Communication status | via LED |
| customs tariff number | 90291000 |
| Dimensions H × W × D | 109×12.9×76.5 mm |
| Monitoring - no voltage | no |
| Monitoring - under voltage | yes |
| Short-circuit and overload | yes |
Product Description
CUBE20S COUNTER MODULE 1X32Bit 2MHz
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
