In Stock Hot Product
503.3283
503.3283 SCAME INTERLOCK.SOCKET 2P+E IP66 32A 6h
$0.00USD
4772 in stock
Key Specifications
Poles::2P+E
Colour::BLUE
Flange::130X260MM_PAR
Volume::0
Supplier Information
SCAME
Products: 16209
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Poles: | 2P+E |
| Colour: | BLUE |
| Flange: | 130X260MM_PAR |
| Volume: | 0 |
| EAN code: | 8001636238043 |
| Quantity: | 1 |
| Dimensions: | 0X0X0 () |
| Net Weight: | 2.595KG |
| Description: | Box |
| Gross weight: | 2.742 KG |
| Hour position: | 6h |
| Minimum order: | 1NR |
| Rated current: | 32A |
| Rated voltage: | 200-250V |
| Dust protection: | Ex tb IIIC T90°C Db IP66 |
| Commercial series: | ADVANCE-GRP[EX] Series |
| Protection degree IP: | IP66 |
| Group and categories EX: | II 2 D |
| Synthetical description: | INTERLOCKED SOCKET |
| Ambient temperature Ta max: | 60 °C |
| Ambient temperature Ta min: | -25 °C |
| Harmonized System Code (HSCode): | 85366990 |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
