3TH2022-6BM4
3TH2022-6BM4 SIEMENS Contactor relay, 22E, EN 50011, 2 NO + 2 NC, Soldering pin connection Screw mounting (d..
$0.00USD
3661 in stock
Key Specifications
:Value
EAN:4011209259997
UPC:Not available
Notes:Product was deleted without replacementSucessor:Replacement: 3RH11221BM40, 3RT19164KA1If you need assistance please contact our local Siemens office
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Value | |
| EAN | 4011209259997 |
| UPC | Not available |
| Notes | Product was deleted without replacementSucessor:Replacement: 3RH11221BM40, 3RT19164KA1If you need assistance please contact our local Siemens office |
| Group Code | R711 |
| Price Group | 41A |
| Metal Factor | LC------ |
| Product Group | 5800 |
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. |
| Quantity Unit | 1 Piece |
| Commodity Code | 85364900 |
| Product family | Not available |
| Net Weight (kg) | 0,180 Kg |
| Country of origin | Turkey |
| LKZ_FDB/ CatalogID | NSE-2-1 |
| PLM Effective Date | Product discontinued since: 01.10.2019 |
| Packaging Quantity | 1 |
| Packaging Dimension | 48,00 x 62,00 x 66,00 |
| Product Description | Contactor relay, 22E, EN 50011, 2 NO + 2 NC, Soldering pin connection Screw mounting (diagonal) DC operation 220 V DC !!! Phased-out product !!! Successor is SIRIUS 3RH21 |
| Interface (EF000594) | - |
| Product Lifecycle (PLM) | PM490:Start of final year of support |
| Export Control Regulations | ECCN : N / AL : N |
| Mounting method (EF000003) | - |
| Standard lead time ex-works | On request |
| Surcharge for Raw Materials | None |
| Package size unit of measure | MM |
| Product Dimensions (W x L x H) | Not available |
| With LED indication (EF005950) | - |
| Manual operation possible (EF005881) | - |
| Article Number (Market Facing Number) | 3TH2022-6BM4 |
| Voltage type for actuating (EF008242) | - |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| Connection type auxiliary circuit (EF006820) | - |
| Rated operation current Ie, 400 V (EF001378) | - |
| Rated control supply voltage Us at DC (EF003980) | - |
| Rated control supply voltage Us at AC 50HZ (EF003978) | - |
| Rated control supply voltage Us at AC 60HZ (EF003979) | - |
| Number of auxiliary contacts as change-over contact (EF003531) | - |
| Number of auxiliary contacts as normally open contact (EF001376) | - |
| Number of auxiliary contacts as normally closed contact (EF001377) | - |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.05.2012 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
| Number of auxiliary contacts as normally open contact, leading (EF007282) | - |
| Number of auxiliary contacts as normally closed contact, delayed switching (EF007281) | - |
