3SU1401-1ME50-1DA1
3SU1401-1ME50-1DA1 SIEMENS SIRIUS ACT: Terminal module (LED module), integrated LED blue, for front plate mo..
$0.00USD
4500 in stock
Key Specifications
:VersionClassificationeClass627-37-92-13eClass7.127-37-92-13eClass827-37-92-13eClass927-37-92-13eClass9.127-37-92-13ETIM5EC002024ETIM6EC002024ETIM7EC002024ETIM8EC002024IDEA45226UNSPSC1539-12-22-21
EAN:4011209965898
UPC:804766463228
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| VersionClassificationeClass627-37-92-13eClass7.127-37-92-13eClass827-37-92-13eClass927-37-92-13eClass9.127-37-92-13ETIM5EC002024ETIM6EC002024ETIM7EC002024ETIM8EC002024IDEA45226UNSPSC1539-12-22-21 | |
| EAN | 4011209965898 |
| UPC | 804766463228 |
| ETIM | 5 |
| IDEA | 4 |
| depth | 31.5 mm |
| width | 30 mm |
| UNSPSC | 15 |
| eClass | 6 |
| height | 32.6 mm |
| ● solid | 0.08 ... 0.08 mm² |
| Group Code | R711 |
| ● maximum | 27 mA |
| Confirmation | |
| Metal Factor | None |
| Date5/14/2022 | Subject to change without notice© Copyright Siemens 2022 |
| Product Group | 5453 |
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. |
| Quantity Unit | 1 Piece |
| Commodity Code | 85318070 |
| Product family | Modules |
| last modified: | 1/27/2022 |
| Net Weight (kg) | 0,020 Kg |
| display version | |
| type of voltage | |
| ● rated value | 23 mA |
| consumed current | |
| firmware version | 1.0.0 |
| hardware version | 1 |
| product function | |
| Country of origin | Czech Republic |
| Test Certificates | other |
| LKZ_FDB/ CatalogID | CC-IC10 |
| Packaging Quantity | 1 |
| product brand name | SIRIUS ACT |
| ● during storage | -40 ... +80 °C |
| Packaging Dimension | 65,00 x 80,00 x 55,00 |
| Product Description | SIRIUS ACT: terminal module (LED module), integrated LED blue, for front plate mounting |
| ambient temperature | |
| degree of pollution | 3 |
| product designation | Terminal module |
| protection class IP | IP20 |
| service life maximum | 20 y |
| ● during operation | -25 ... +60 °C |
| design of the product | with integrated LED |
| protocol is supported | |
| ● solid or stranded | 0.08 ... 0.08 mm² |
| ● status Tx/Rx link | No |
| power loss [W] typical | 0.115 W |
| ● PROFIsafe protocol | No |
| Product Lifecycle (PLM) | PM300:Active Product |
| General Product Approval | Declaration of Conformity |
| Special Test Certificate | Confirmation |
| product type designation | 3SU1 |
| ● diagnostics function | Yes |
| ● of the input voltage | DC |
| color of the light source | blue |
| Export Control Regulations | AL : N / ECCN : N |
| Standard lead time ex-works | 15 Day/Days |
| Surcharge for Raw Materials | None |
| Package size unit of measure | MM |
| ● of the operating voltage | DC |
| Substance Prohibitance (Date) | 12/19/2016 |
| type of electrical connection | Insulation displacement connection |
| ● reverse polarity protection | Yes; Ribbon cable can be rotated 180°. |
| ● solid with core end processing | 0.08 ... 0.08 mm² |
| connectable conductor cross-section | |
| surge voltage resistance rated value | 0.8 kV |
| Article Number (Market Facing Number) | 3SU1401-1ME50-1DA1 |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| reference code according to IEC 81346-2 | K |
| fastening method of modules and accessories | Front plate mounting |
| type of connectable conductor cross-sections | Ribbon cable 7-pole, 7 x 0.08 mm2 |
| ● finely stranded with core end processing | 0.08 mm² |
| ● finely stranded without core end processing | 0.08 ... 0.08 mm² |
| Type of electrical accessory/spare part (EF005722) | - |
| Type of mechanical accessory/spare part (EF005994) | - |
| Region Specific PriceGroup / Headquarter Price Group | 41J / 41J |
| AWG number as coded connectable conductor cross section | 28 ... 28 |
| software version with STEP 7 in the TIA Portal required | V13 SP1 (V13 SP1 and V14 with HSP0132) |
| connectable conductor cross-section for auxiliary contacts | |
| environmental category during operation according to IEC 60721 | 3M6, 3S2, 3B2, 3K6 (with relative air humidity of 10 ... 95%, no condensation in operation permitted) |
| ● for diagnostic function: Supply voltage monitoring power LED | Yes |
| Compliance with the substance restrictions according to RoHS directive | Since: 19.12.2016 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Lead CAS-No. 7439-92-1 > 0, 1 % (w / w)Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w):LeadBased on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation.Lead monoxide (lead ... CAS-No. 1317-36-8 > 0, 1 % (w / w)Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w):Lead monoxide (lead oxide)Based on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation. |
| explosion protection marking for intrinsic safety of related equipment EEx ia | No |
| explosion protection marking for intrinsic safety of related equipment EEx ib | No |
| General Product ApprovalDeclaration of ConformityTest CertificatesConfirmationUK Declaration of ConformityType Test Certificates/Test ReportTest CertificatesotherSpecial Test CertificateConfirmation | General Product Approval |
