3SB2455-2A
3SB2455-2A SIEMENS Lampholder, Wedge base W2 x 4.6 d, with soldering pins for soldering pin connection
$0.00USD
4162 in stock
Key Specifications
:
EAN:4011209028500
UPC:754554866062
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4011209028500 |
| UPC | 754554866062 |
| ETIM | 5 |
| IDEA | 4 |
| depth | 29 mm |
| width | 18 mm |
| UNSPSC | 14 |
| eClass | 6 |
| height | 19 mm |
| ● at AC | |
| Group Code | R711 |
| Confirmation | |
| Metal Factor | LAO----- |
| Date5/10/2022 | Subject to change without notice© Copyright Siemens 2022 |
| Product Group | 5834 |
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. |
| Quantity Unit | 1 Piece |
| socket design | W2 x 4.6d |
| Commodity Code | 85366190 |
| Product family | Contact blocks and lampholders |
| last modified: | 1/6/2021 |
| Net Weight (kg) | 0,000001 Kg |
| type of voltage | |
| fastening method | clip-on |
| ● light source | No |
| Country of origin | Czech Republic |
| operating voltage | |
| product component | |
| LKZ_FDB/ CatalogID | CC-IC10 |
| Packaging Quantity | 1 |
| product brand name | SIRIUS |
| ● during storage | -40 ... +80 °C |
| Packaging Dimension | 35,00 x 35,00 x 10,00 |
| Product Description | Lampholder, Wedge base W2 x 4.6 d, with soldering pins for soldering pin connection |
| ambient temperature | |
| product designation | Lampholder |
| protection class IP | |
| ● of the terminal | IP00 |
| Lamp type (EF002423) | - |
| ● during operation | -25 ... +60 °C |
| ● of the enclosure | IP40 |
| number of lampholders | 1 |
| ● at DC rated value | 5 ... 60 V |
| Colour lamp (EF001402) | - |
| Lamp holder (EF000048) | Wedge Base W 2x4.6d |
| Product Lifecycle (PLM) | PM300:Active Product |
| ● at 24 V rated value | 10 A |
| ● at 60 V rated value | 10 A |
| General Product Approval | Declaration of Conformity |
| product type designation | 3SB2 |
| — at 50 Hz rated value | 5 ... 60 V |
| — at 60 Hz rated value | 5 ... 60 V |
| ● at 110 V rated value | 10 A |
| ● at 230 V rated value | 10 A |
| Export Control Regulations | AL : N / ECCN : N |
| Standard lead time ex-works | 10 Day/Days |
| Surcharge for Raw Materials | None |
| suitability for integration | front element |
| Package size unit of measure | MM |
| Type of fastening (EF002442) | Front fastening |
| With light source (EF005905) | false |
| operational current at AC-12 | |
| operational current at AC-15 | |
| operational current at DC-12 | |
| operational current at DC-13 | |
| ● of the operating voltage | AC/DC |
| Substance Prohibitance (Date) | 07/01/2006 |
| type of electrical connection | solder pin connectors |
| With integrated diode (EF001400) | - |
| Rated voltage Ue at DC (EF007031) | ['5', '60'] |
| Transformer integrated (EF001358) | - |
| product function positive opening | No |
| Article Number (Market Facing Number) | 3SB2455-2A |
| Voltage type for actuating (EF008242) | - |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| Rated voltage Ue at AC 50 Hz (EF007029) | ['5', '60'] |
| Rated voltage Ue at AC 60 Hz (EF007030) | ['5', '60'] |
| reference code according to IEC 81346-2 | P |
| Connection type auxiliary circuit (EF006820) | Soldering flag connection |
| number of CO contacts for auxiliary contacts | 0 |
| number of NC contacts for auxiliary contacts | 0 |
| number of NO contacts for auxiliary contacts | 0 |
| vibration resistance according to IEC 60068-2-6 | 20 ... 200 Hz: 5g |
| Region Specific PriceGroup / Headquarter Price Group | 41J / 41J |
| With integrated voltage decreasing resistor (EF001399) | - |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.07.2006 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
| General Product ApprovalDeclaration of ConformityUK Declaration of ConformityotherConfirmation | General Product Approval |
