3SB2204-6BC06
3SB2204-6BC06 SIEMENS Indicator light, 16 mm, round, plastic, red, Lampholder W2 x 4.6 d, without lamp
$0.00USD
3086 in stock
Key Specifications
:
EAN:4011209028135
UPC:754554482460
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4011209028135 |
| UPC | 754554482460 |
| ETIM | 5 |
| IDEA | 4 |
| UNSPSC | 14 |
| eClass | 6 |
| Group Code | R711 |
| Metal Factor | LA------ |
| Date5/14/2022 | Subject to change without notice© Copyright Siemens 2022 |
| Miscellaneous | Special Test Certificate |
| Product Group | 5834 |
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. |
| Quantity Unit | 1 Piece |
| socket design | W2 x 4.6d without lamp |
| Commodity Code | 85318070 |
| Product family | Complete units |
| last modified: | 1/26/2022 |
| Net Weight (kg) | 0,020 Kg |
| mounting height | 9 mm |
| fastening method | front plate mounting |
| product function | |
| Country of origin | Czech Republic |
| Test Certificates | other |
| mounting diameter | 16 mm |
| LKZ_FDB/ CatalogID | CC-IC10 |
| Packaging Quantity | 1 |
| installation depth | 50 mm |
| installation width | 19 mm |
| product brand name | SIRIUS |
| ● during storage | -40 ... +80 °C |
| Packaging Dimension | 50,00 x 80,00 x 53,00 |
| Product Description | Indicator light, 16 mm, round, plastic, red, Lampholder W2 x 4.6 d, without lamp |
| ambient temperature | |
| product designation | Indicator lights |
| protection class IP | IP65 |
| ● during operation | -25 ... +60 °C |
| ● positive opening | No |
| design of the product | Complete unit round |
| number of lampholders | 1 |
| Colour lens (EF000207) | Red |
| material of the holder | Plastic |
| Product Lifecycle (PLM) | PM300:Active Product |
| Type of lens (EF008343) | - |
| Voltage type (EF000187) | AC/DC |
| General Product Approval | Declaration of Conformity |
| Hole diameter (EF000079) | 16.0 |
| Width opening (EF004565) | 19.0 |
| number of command points | 0 |
| product type designation | 3SB2 |
| type of unlocking device | without |
| Height opening (EF004778) | 9.0 |
| Export Control Regulations | AL : N / ECCN : N |
| With front ring (EF006014) | false |
| Standard lead time ex-works | 2 Day/Days |
| Surcharge for Raw Materials | None |
| ● EMERGENCY STOP function | No |
| Colour front ring (EF002429) | - |
| Package size unit of measure | MM |
| With light source (EF005905) | false |
| number of switching elements | 0 |
| product component front ring | No |
| Substance Prohibitance (Date) | 07/01/2006 |
| number of switching positions | 2 |
| operating voltage rated value | 5 ... 60 V |
| type of electrical connection | tab terminals |
| Material front ring (EF005972) | - |
| Type of lamp socket (EF008229) | W2 x 4.6 |
| color of the actuating element | red |
| product component light source | No |
| design of the actuating element | indicator light |
| Construction type lens (EF006253) | - |
| material of the actuating element | plastic |
| shape of the installation opening | round |
| Degree of protection (IP) (EF005474) | IP65 |
| Article Number (Market Facing Number) | 3SB2204-6BC06 |
| Number of indicator lights (EF001965) | 1 |
| Rated operating voltage Ue (EF002418) | ['5', '60'] |
| Degree of protection (NEMA) (EF011959) | - |
| Type of electric connection (EF003961) | Flat plug-in connection |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| product extension optional light source | Yes |
| reference code according to IEC 81346-2 | P |
| type of voltage of the operating voltage | AC/DC |
| number of CO contacts for auxiliary contacts | 0 |
| number of NC contacts for auxiliary contacts | 0 |
| number of NO contacts for auxiliary contacts | 0 |
| tightening torque of the screws in the bracket | 0.4 N·m |
| vibration resistance according to IEC 60068-2-6 | 20 ... 200 Hz: 5g |
| Region Specific PriceGroup / Headquarter Price Group | 41J / 41J |
| environmental category during operation according to IEC 60721 | 3K6 |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.07.2006 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
| General Product ApprovalDeclaration of ConformityUK Declaration of ConformityTest CertificatesotherMiscellaneousSpecial Test CertificateConfirmation | General Product Approval |
