3SB2001-6BF06
3SB2001-6BF06 SIEMENS Indicator light, 16 mm, round, plastic, blue, with concentric rings
$0.00USD
3344 in stock
Key Specifications
:
EAN:4011209027954
UPC:754554865690
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4011209027954 |
| UPC | 754554865690 |
| ETIM | 5 |
| IDEA | 4 |
| UNSPSC | 14 |
| eClass | 6 |
| Group Code | R711 |
| Date5/4/2022 | Subject to change without notice© Copyright Siemens 2022 |
| Metal Factor | None |
| Product Group | 5834 |
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. |
| Quantity Unit | 1 Piece |
| Commodity Code | 85389099 |
| Product family | Actuating and signaling elements |
| last modified: | 1/26/2022 |
| Net Weight (kg) | 0,004 Kg |
| mounting height | 9 mm |
| fastening method | front plate mounting |
| product function | |
| Country of origin | Czech Republic |
| Test Certificates | other |
| mounting diameter | 16 mm |
| LKZ_FDB/ CatalogID | CC-IC10 |
| Packaging Quantity | 1 |
| installation depth | 50 mm |
| installation width | 19 mm |
| product brand name | SIRIUS |
| ● during storage | -40 ... +80 °C |
| Packaging Dimension | 20,00 x 25,00 x 20,00 |
| Product Description | Indicator light, 16 mm, round, plastic, blue, with concentric rings |
| ambient temperature | |
| product designation | Indicator lights |
| protection class IP | IP65 |
| ● during operation | -25 ... +70 °C |
| design of the product | Single device round |
| Colour lens (EF000207) | Blue |
| material of the holder | Plastic |
| Product Lifecycle (PLM) | PM300:Active Product |
| Type of lens (EF008343) | Flat |
| General Product Approval | Declaration of Conformity |
| Hole diameter (EF000079) | 16.0 |
| Special Test Certificate | Confirmation |
| Width opening (EF004565) | 19.0 |
| number of command points | 0 |
| product type designation | 3SB2 |
| type of unlocking device | without |
| Height opening (EF004778) | 9.0 |
| Export Control Regulations | AL : N / ECCN : N |
| With front ring (EF006014) | false |
| ● EMERGENCY OFF function | No |
| Standard lead time ex-works | 2 Day/Days |
| Surcharge for Raw Materials | None |
| ● EMERGENCY STOP function | No |
| Colour front ring (EF002429) | - |
| Package size unit of measure | MM |
| product component front ring | No |
| Substance Prohibitance (Date) | 07/01/2006 |
| number of switching positions | 0 |
| Material front ring (EF005972) | - |
| color of the actuating element | blue |
| shape of the actuating element | Concentric rings |
| design of the actuating element | indicator light |
| Construction type lens (EF006253) | Round |
| material of the actuating element | plastic |
| shape of the installation opening | round |
| Article Number (Market Facing Number) | 3SB2001-6BF06 |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| outer diameter of the actuating element | 19 mm |
| product extension optional light source | No |
| reference code according to IEC 81346-2 | P |
| tightening torque of the screws in the bracket | 0.4 N·m |
| vibration resistance according to IEC 60068-2-6 | 20 ... 200 Hz: 5g |
| Degree of protection (IP), front side (EF003118) | IP65 |
| Region Specific PriceGroup / Headquarter Price Group | 41J / 41J |
| Suitable for number of built-in signal lights (EF006669) | 1 |
| environmental category during operation according to IEC 60721 | 3K6 |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.07.2006 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
| General Product ApprovalDeclaration of ConformityTest CertificatesUK Declaration of ConformityMiscellaneousTest CertificatesotherSpecial Test CertificateConfirmation | General Product Approval |
Product Description
Lamp holder, signage lamp with concentric rings, blue
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
