3RV1986-0BA0
3RV1986-0BA0 SIEMENS Lever-type rotary operating mechanism with lock/door interlock for size 3RV1. 8
$0.00USD
4410 in stock
Key Specifications
:VersionClassificationeClass1.227-37-04-15eClass627-37-04-15eClass7.127-37-04-15eClass827-37-04-15eClass927-37-04-15eClass9.127-37-04-15ETIM7EC000230ETIM8EC000230IDEA45219UNSPSC1539-12-22-21
EAN:4011209769328
UPC:040892960396
ETIM:7
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| VersionClassificationeClass1.227-37-04-15eClass627-37-04-15eClass7.127-37-04-15eClass827-37-04-15eClass927-37-04-15eClass9.127-37-04-15ETIM7EC000230ETIM8EC000230IDEA45219UNSPSC1539-12-22-21 | |
| EAN | 4011209769328 |
| UPC | 040892960396 |
| ETIM | 7 |
| IDEA | 4 |
| Notes | Sucessor:successor for SENTRON MCCB accessory 3VA9 |
| UNSPSC | 15 |
| eClass | 1.2 |
| Group Code | R711 |
| Confirmation | |
| Metal Factor | None |
| Date7/11/2022 | Subject to change without notice© Copyright Siemens 2022 |
| Product Group | 5371 |
| Product class | C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. |
| Quantity Unit | 1 Piece |
| Commodity Code | 85389099 |
| Product family | Rotary operating mechanisms, mounting accessories |
| last modified: | 12/23/2020 |
| Net Weight (kg) | 1,033 Kg |
| Country of origin | Italy |
| LKZ_FDB/ CatalogID | CC-IC10 |
| PLM Effective Date | Product phase-out since: 01.10.2022 |
| Packaging Quantity | 1 |
| product brand name | |
| Lockable (EF000113) | - |
| Packaging Dimension | 161,00 x 497,00 x 73,00 |
| Product Description | Lever-type rotary operating mechanism with lock/door interlock for size 3RV1. 8 |
| product designation | |
| Product Lifecycle (PLM) | PM300:Active Product |
| General Product Approval | Declaration of Conformity |
| Export Control Regulations | AL : N / ECCN : N |
| Standard lead time ex-works | 20 Day/Days |
| Surcharge for Raw Materials | None |
| Package size unit of measure | MM |
| With axis extension (EF001968) | - |
| With door interlock (EF001969) | - |
| With handle red/yellow (EF001970) | - |
| Article Number (Market Facing Number) | 3RV1986-0BA0 |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| Region Specific PriceGroup / Headquarter Price Group | 41E / 41E |
| Compliance with the substance restrictions according to RoHS directive | Since: 08.01.2008 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
| General Product ApprovalDeclaration of ConformityMarine / ShippingConfirmationotherConfirmation | General Product Approval |
Product Description
ACC. BY GIRAT LEVER. WITH ENCLAV. P/PADLOCK AND DOOR FOR TAM. 3RV1. 8. Manufactured to order. Non-Cancelable Non-Returnable.
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
