3RT1965-5AP32
3RT1965-5AP32 SIEMENS Changeover operating mechanism for contactors 3RT106, 3RT146 AC (50...60 Hz) / DC oper..
$0.00USD
3301 in stock
Key Specifications
:Confirmation
EAN:4011209584204
UPC:804766799617
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Confirmation | |
| EAN | 4011209584204 |
| UPC | 804766799617 |
| ETIM | 5 |
| IDEA | 4 |
| UNSPSC | 15 |
| eClass | 6 |
| Group Code | R711 |
| ● 2 at AC | |
| Date5/3/2022 | Subject to change without notice© Copyright Siemens 2022 |
| Metal Factor | L-R----- |
| Product Group | 3729 |
| Product class | C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. |
| Quantity Unit | 1 Piece |
| Commodity Code | 85045000 |
| Product family | Solenoid coils |
| last modified: | 1/12/2021 |
| Net Weight (kg) | 0,780 Kg |
| Country of origin | Germany |
| Marine / Shipping | other |
| LKZ_FDB/ CatalogID | CC-IC10 |
| Packaging Quantity | 1 |
| product brand name | SIRIUS |
| Packaging Dimension | 110,00 x 125,00 x 172,00 |
| Product Description | Changeover operating mechanism for contactors 3RT106, 3RT146 AC (50...60 Hz) / DC operation, 220 ... 240 V Operating mechanism: Standard,economy circuit Spring-type terminal |
| product designation | Magnet coil |
| control supply voltage | |
| Product Lifecycle (PLM) | PM300:Active Product |
| ● 2 at DC rated value | 240 V |
| General Product Approval | EMC |
| — at 50 Hz rated value | 240 V |
| — at 60 Hz rated value | 240 V |
| Declaration of Conformity | Test Certificates |
| Export Control Regulations | AL : N / ECCN : EAR99 |
| Standard lead time ex-works | 5 Day/Days |
| Surcharge for Raw Materials | None |
| Package size unit of measure | MM |
| UK Declaration of Conformity | Type Test Certificates/Test Report |
| Article Number (Market Facing Number) | 3RT1965-5AP32 |
| Voltage type for actuating (EF008242) | AC/DC |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| type of voltage of the control supply voltage | AC/DC |
| Rated control supply voltage Us at DC (EF003980) | ['220', '240'] |
| Region Specific PriceGroup / Headquarter Price Group | 41B / 41B |
| Rated control supply voltage Us at AC 50HZ (EF003978) | ['220', '240'] |
| Rated control supply voltage Us at AC 60HZ (EF003979) | ['220', '240'] |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.05.2012 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Lead CAS-No. 7439-92-1 > 0, 1 % (w / w)Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w):LeadBased on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation. |
| General Product ApprovalEMCDeclaration of ConformityConfirmationDeclaration of ConformityTest CertificatesMarine / ShippingUK Declaration of ConformityType Test Certificates/Test ReportSpecial Test CertificateMarine / ShippingotherRailwayConfirmationMiscellaneousSpecial Test Certificate | General Product Approval |
Product Description
REMOVABLE COIL FOR size S10 P/SIRIUS Contactors 3RT106/3RT146 ACCTO. AC/DC 220-240V UC DRIVE: CONVENTIONAL Spring connection. Manufactured to order. Non-Cancelable Non-Returnable.
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
