3NW6604-4
3NW6604-4 SIEMENS SENTRON, cylindrical fuse link, 10x85 mm, 4 A, gPV, Un DC: 1500 V
$0.00USD
4934 in stock
Key Specifications
:
EAN:4001869502625
UPC:Not available
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4001869502625 |
| UPC | Not available |
| ETIM | 5 |
| UNSPSC | 15 |
| eClass | 6 |
| Group Code | P310 |
| net weight | 15 g |
| Confirmation | |
| Date5/3/2022 | |
| Metal Factor | -33----- |
| Product Group | 5764 |
| Product class | C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. |
| Quantity Unit | 1 Piece |
| Commodity Code | 85361010 |
| Product family | PV Cylindrical Fuses |
| Net Weight (kg) | 0,015 Kg |
| Size (EF000088) | Other |
| Country of origin | Slovenia |
| mounting position | Any, preferably vertical |
| LKZ_FDB/ CatalogID | LV10.1 |
| Packaging Quantity | 1 |
| product brand name | SENTRON |
| Packaging Dimension | 88,00 x 106,50 x 10,00 |
| Product Description | SENTRON, cylindrical fuse link, 10x85 mm, 4 A, gPV, Un DC: 1500 V |
| product designation | Cylindrical fuse link |
| size of the fuse link | 10 x 85 mm |
| Minimum order quantity | 10 |
| supply voltage / at DC | 1 500 V |
| Product Lifecycle (PLM) | PM300:Active Product |
| Voltage type (EF000187) | AC |
| With striker (EF008175) | false |
| General Product Approval | other |
| Rated voltage (EF003977) | ['10', '1500'] |
| Rated voltage (EF007681) | 1500 |
| Export Control Regulations | AL : N / ECCN : N |
| Nominal current (EF000001) | 4 |
| Standard lead time ex-works | 2 Day/Days |
| Surcharge for Raw Materials | None |
| product component / striker | No |
| Breaking capacity (EF005617) | - |
| Package size unit of measure | MM |
| Utilization category (EF002572) | Other |
| operating class of the fuse link | gPV |
| Release characteristic (EF000889) | - |
| operational current / rated value | 4 A |
| Rated operating frequency (EF007370) | ['62', '45'] |
| Article Number (Market Facing Number) | 3NW6604-4 |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| operational current / at AC / rated value | 4 A |
| type of voltage / of the operating voltage | DC |
| Region Specific PriceGroup / Headquarter Price Group | 13K / 1DN |
| General Product ApprovalotherConfirmationMiscellaneous | General Product Approval |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.04.2014 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
Product Description
PV-FUSE 10X85 4A 1500V GPV ( ** ATTENTION : Price per 1 Unit and Minimum Quantity / Order Multiple 10 Units ** ). Manufactured to order. Non-Cancelable Non-Returnable.
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
