3NH5723
3NH5723 SIEMENS SITOR fuse holder 50 A 690 V 1-pole with bolt terminal with fixing dimension 75 mm
$0.00USD
3589 in stock
Key Specifications
:
EAN:4001869498164
UPC:Not available
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4001869498164 |
| UPC | Not available |
| ETIM | 5 |
| width | 28 mm |
| UNSPSC | 14 |
| eClass | 6 |
| height | 98 mm |
| ● at DC | 690 V |
| Group Code | P310 |
| net weight | 187 g |
| Confirmation | |
| Date5/2/2022 | |
| Metal Factor | LHB----- |
| Product Group | 5530 |
| Product class | C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. |
| Quantity Unit | 1 Piece |
| Commodity Code | 85389099 |
| Product family | LV HRC Design |
| supply voltage | |
| Net Weight (kg) | 0,183 Kg |
| number of poles | 1 |
| fastening method | fixed mounting |
| Country of origin | Czech Republic |
| LKZ_FDB/ CatalogID | LV10 |
| Packaging Quantity | 1 |
| product brand name | SENTRON |
| Packaging Dimension | 100,00 x 90,00 x 55,00 |
| Product Description | SITOR fuse holder 50 A 690 V 1-pole with bolt terminal with fixing dimension 75 mm |
| operational current | |
| product designation | LV HRC fuse system |
| utilization category | Without |
| design of the product | LV HRC fuse base for screw fixing |
| Minimum order quantity | 3 |
| Product Lifecycle (PLM) | PM300:Active Product |
| ● at AC / rated value | 690 V |
| General Product Approval | Declaration of Conformity |
| Rated current (EF000227) | 50 |
| Export Control Regulations | AL : N / ECCN : N |
| Number of poles (EF001391) | 1 |
| Standard lead time ex-works | 2 Day/Days |
| Surcharge for Raw Materials | None |
| ● at 35 °C / rated value | 47 A |
| ● at 40 °C / rated value | 46 A |
| ● at 45 °C / rated value | 44.52 A |
| ● at 50 °C / rated value | 43 A |
| ● at 55 °C / rated value | 41.52 A |
| ● at 60 °C / rated value | 40.52 A |
| ● at 65 °C / rated value | 38.52 A |
| ● at 70 °C / rated value | 37 A |
| Bus-mounting type (EF002573) | - |
| Construction size (EF002566) | Other |
| Package size unit of measure | MM |
| ● for main current circuit | Stud terminal |
| type of electrical connection | for mounting on mounting plate |
| Swivelling mechanism (EF002574) | false |
| fastening method / bus-mounting | No |
| Article Number (Market Facing Number) | 3NH5723 |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| product component / swivel-in mechanism | No |
| design of the thread / of the connection screw | M5 |
| Region Specific PriceGroup / Headquarter Price Group | 12J / 1BM |
| tightening torque / with screw-type terminals / maximum | 2 N·m |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.09.2013 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
| General Product ApprovalDeclaration of ConformityotherConfirmationUK Declaration of ConformityMiscellaneous | General Product Approval |
Product Description
FUSE HOLDER SITOR 50A 690V 1 POLE WITH BOLT CONNECTION WITH DIMENSION FIXATION 75MM ( ** ATTENTION : Price per 1 Unit and Minimum Quantity / Multipurpose Order 3 Units ** ). Manufactured to order. Non
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
