3NE8702-1
3NE8702-1 SIEMENS SITOR fuse link, with Bolt-on links, NH000, In: 40 A, gR, Un AC: 690 V, Un DC: 440 V, fron..
$0.00USD
3799 in stock
Key Specifications
:Confirmation
EAN:4011209457348
UPC:Not available
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Confirmation | |
| EAN | 4011209457348 |
| UPC | Not available |
| ETIM | 5 |
| UNSPSC | 15 |
| eClass | 6 |
| ● at DC | 440 V |
| Group Code | P310 |
| ● maximum | 12 W |
| ● minimum | -20 °C |
| Date5/8/2022 | |
| Metal Factor | LHP----- |
| Miscellaneous | |
| Product Group | 5540 |
| Product class | B: return restricted, please contact your Siemens partner/contact |
| Quantity Unit | 1 Piece |
| Commodity Code | 85361050 |
| Product family | LV HRC Design |
| power loss [W] | 12 W |
| supply voltage | |
| Net Weight (kg) | 0,144 Kg |
| Country of origin | China |
| mounting position | Any, preferably vertical |
| LKZ_FDB/ CatalogID | LV10.1 |
| Packaging Quantity | 1 |
| product brand name | SENTRON |
| Packaging Dimension | 60,00 x 105,00 x 24,00 |
| Product Description | SITOR fuse link, with Bolt-on links, NH000, In: 40 A, gR, Un AC: 690 V, Un DC: 440 V, front indicator |
| operational current | |
| product description | Not non-interchangeable |
| product designation | SITOR fuse link |
| design of the product | With bolt-on links |
| Minimum order quantity | 10 |
| environmental category | -20 to +50 at 95% relative humidity |
| Product Lifecycle (PLM) | PM300:Active Product |
| Voltage type (EF000187) | - |
| design of the fuse link | SITOR, LV HRC design |
| ● at AC / rated value | 690 V |
| General Product Approval | Declaration of Conformity |
| Rated current (EF000227) | 40 |
| Rated voltage (EF000228) | 690 |
| varying load factor (WL) | 0.9 |
| Export Control Regulations | AL : N / ECCN : N |
| switching capacity current | |
| Standard lead time ex-works | 2 Day/Days |
| Surcharge for Raw Materials | None |
| ● at 30 °C / rated value | 40 A |
| ● at 40 °C / rated value | 40 A |
| ● at 45 °C / rated value | 40 A |
| ● at 50 °C / rated value | 39.6 A |
| ● at 55 °C / rated value | 39.2 A |
| ● at 60 °C / rated value | 38.8 A |
| Construction size (EF002566) | NH000 |
| Package size unit of measure | MM |
| Utilization category (EF002572) | gR (general purpose semiconductor protection) |
| design of the switching contact | With bolt-on links, silver-plated |
| operating class of the fuse link | gR |
| Rated switching capacity (EF002563) | 200.0 |
| Article Number (Market Facing Number) | 3NE8702-1 |
| design of an identification indicator | front indicator |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| ambient temperature / during operation | |
| Type of fuse status indicator (EF004473) | Top fuse status indicator |
| type of voltage / of the operating voltage | AC/DC |
| ● according to IEC 60947-2 / rated value | 200 kA |
| size of fuse system / according to EN 60269-1 | NH000 |
| Insulated metal gripping lugs (IMGL) (EF012538) | - |
| ● at DC / according to IEC 60947-2 / rated value | 50 kA |
| Region Specific PriceGroup / Headquarter Price Group | 15I / 1DM |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.07.2006 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Lead CAS-No. 7439-92-1 > 0, 1 % (w / w)Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w):LeadBased on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation. |
| ● for rated value of the current / at AC / in hot operating state / per pole | 12 W |
| General Product ApprovalDeclaration of ConformityConfirmationUK Declaration of ConformityotherMiscellaneous | General Product Approval |
Product Description
SET OF FUSES SITOR (DIN 43653, TAM.00 COMPACT) 40A, AC 690V, BEP.-MASS 80MM ( ** ATTENTION : Price per 1 Unit and Minimum Quantity / Order Multiple 10 Units ** ). Cancelations and returns limited. Con
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
