3NE4118
3NE4118 SIEMENS SITOR fuse link, with blade contacts, NH0, In: 63 A, aR, Un AC: 1000 V, Un DC: 440 V, front ..
$0.00USD
3460 in stock
Key Specifications
:VersionClassificationeClass627-14-20-05eClass7.127-14-20-05eClass827-14-20-05eClass927-14-20-05eClass9.127-14-20-05ETIM5EC000055ETIM6EC000055ETIM7EC000055ETIM8EC000055IDEA44982UNSPSC1539-12-16-28
EAN:4011209005044
UPC:Not available
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| VersionClassificationeClass627-14-20-05eClass7.127-14-20-05eClass827-14-20-05eClass927-14-20-05eClass9.127-14-20-05ETIM5EC000055ETIM6EC000055ETIM7EC000055ETIM8EC000055IDEA44982UNSPSC1539-12-16-28 | |
| EAN | 4011209005044 |
| UPC | Not available |
| ETIM | 5 |
| IDEA | 4 |
| UNSPSC | 15 |
| eClass | 6 |
| Group Code | P310 |
| Metal Factor | LHP----- |
| Product Group | 5540 |
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. |
| Quantity Unit | 1 Piece |
| Commodity Code | 85361050 |
| Product family | LV HRC Design |
| Net Weight (kg) | 0,268 Kg |
| Country of origin | Greece |
| LKZ_FDB/ CatalogID | LV10.1 |
| Packaging Quantity | 1 |
| Packaging Dimension | 94,00 x 127,00 x 63,00 |
| Product Description | SITOR fuse link, with blade contacts, NH0, In: 63 A, aR, Un AC: 1000 V, Un DC: 440 V, front indicator |
| Minimum order quantity | 3 |
| Product Lifecycle (PLM) | PM300:Active Product |
| Voltage type (EF000187) | - |
| Rated current (EF000227) | 63 |
| Rated voltage (EF000228) | 1000 |
| Export Control Regulations | AL : N / ECCN : N |
| Standard lead time ex-works | 20 Day/Days |
| Surcharge for Raw Materials | None |
| Construction size (EF002566) | NH0 |
| Package size unit of measure | MM |
| Utilization category (EF002572) | aR (accompanied semiconductor protection) |
| Rated switching capacity (EF002563) | 100.0 |
| Article Number (Market Facing Number) | 3NE4118 |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| Type of fuse status indicator (EF004473) | Top fuse status indicator |
| Insulated metal gripping lugs (IMGL) (EF012538) | - |
| Region Specific PriceGroup / Headquarter Price Group | 15I / 1DM |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.07.2006 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
