In Stock Hot Product
3NE1230-2
3NE1230-2 SIEMENS SITOR fuse link, with blade contacts, NH1, In: 315 A, gR, Un AC: 690 V, Un DC: 250 V, fron..
$0.00USD
3759 in stock
Key Specifications
:VersionClassificationeClass627-14-20-05eClass7.127-14-20-05eClass827-14-20-05eClass927-14-20-05eClass9.127-14-20-05ETIM5EC000055ETIM6EC000055ETIM7EC000055ETIM8EC000055IDEA44982UNSPSC1539-12-16-28
EAN:4011209568105
UPC:Not available
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| VersionClassificationeClass627-14-20-05eClass7.127-14-20-05eClass827-14-20-05eClass927-14-20-05eClass9.127-14-20-05ETIM5EC000055ETIM6EC000055ETIM7EC000055ETIM8EC000055IDEA44982UNSPSC1539-12-16-28 | |
| EAN | 4011209568105 |
| UPC | Not available |
| ETIM | 5 |
| IDEA | 4 |
| UNSPSC | 15 |
| eClass | 6 |
| Group Code | P310 |
| Metal Factor | LHP----- |
| Product Group | 5540 |
| Product class | B: return restricted, please contact your Siemens partner/contact |
| Quantity Unit | 1 Piece |
| Commodity Code | 85361090 |
| Product family | LV HRC Design |
| Net Weight (kg) | 0,596 Kg |
| Country of origin | Greece |
| LKZ_FDB/ CatalogID | LV10.1 |
| Packaging Quantity | 1 |
| Packaging Dimension | 178,00 x 200,00 x 85,00 |
| Product Description | SITOR fuse link, with blade contacts, NH1, In: 315 A, gR, Un AC: 690 V, Un DC: 250 V, front indicator |
| Minimum order quantity | 3 |
| Product Lifecycle (PLM) | PM300:Active Product |
| Voltage type (EF000187) | - |
| Rated current (EF000227) | 315 |
| Rated voltage (EF000228) | 690 |
| Export Control Regulations | AL : N / ECCN : N |
| Standard lead time ex-works | 2 Day/Days |
| Surcharge for Raw Materials | None |
| Construction size (EF002566) | NH1 |
| Package size unit of measure | MM |
| Utilization category (EF002572) | gR (general purpose semiconductor protection) |
| Rated switching capacity (EF002563) | 100.0 |
| Article Number (Market Facing Number) | 3NE1230-2 |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| Type of fuse status indicator (EF004473) | Top fuse status indicator |
| Insulated metal gripping lugs (IMGL) (EF012538) | - |
| Region Specific PriceGroup / Headquarter Price Group | 15I / 1DM |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.07.2006 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
Product Description
SET OF FUSES SITOR CLASS SERVICE GR, DIN 43620 315A, AC 500V (TAM. 1) ( ** ATTENTION : Price per 1 Unit and Minimum Quantity / Order Multiple 3 Units ** ). Cancelations and returns limited. Consult co
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
