3NC3336-6U
3NC3336-6U SIEMENS SITOR fuse link, with female thread on both sides, NH3, In: 630 A, aR, Un AC: 1000 V, Un ..
$0.00USD
4780 in stock
Key Specifications
:VersionClassificationeClass627-14-20-05eClass7.127-14-20-05eClass827-14-20-05eClass927-14-20-05eClass9.127-14-20-05ETIM5EC000055ETIM6EC000055ETIM7EC000055ETIM8EC000055UNSPSC1539-12-16-26
EAN:4001869502762
UPC:887621785024
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| VersionClassificationeClass627-14-20-05eClass7.127-14-20-05eClass827-14-20-05eClass927-14-20-05eClass9.127-14-20-05ETIM5EC000055ETIM6EC000055ETIM7EC000055ETIM8EC000055UNSPSC1539-12-16-26 | |
| EAN | 4001869502762 |
| UPC | 887621785024 |
| ETIM | 5 |
| UNSPSC | 15 |
| eClass | 6 |
| Group Code | P310 |
| Metal Factor | LHP----- |
| Product Group | 5540 |
| Product class | C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. |
| Quantity Unit | 1 Piece |
| Commodity Code | 85361090 |
| Product family | LV HRC Design |
| Net Weight (kg) | 0,892 Kg |
| Country of origin | Greece |
| LKZ_FDB/ CatalogID | LV10.1 |
| Packaging Quantity | 1 |
| Packaging Dimension | 100,00 x 255,00 x 86,00 |
| Product Description | SITOR fuse link, with female thread on both sides, NH3, In: 630 A, aR, Un AC: 1000 V, Un DC: 440 V, front indicator |
| Minimum order quantity | 3 |
| Product Lifecycle (PLM) | PM300:Active Product |
| Voltage type (EF000187) | - |
| Rated current (EF000227) | 630 |
| Rated voltage (EF000228) | 1000 |
| Export Control Regulations | AL : N / ECCN : N |
| Standard lead time ex-works | 2 Day/Days |
| Surcharge for Raw Materials | None |
| Construction size (EF002566) | NH3 |
| Package size unit of measure | MM |
| Utilization category (EF002572) | aR (accompanied semiconductor protection) |
| Rated switching capacity (EF002563) | 100.0 |
| Article Number (Market Facing Number) | 3NC3336-6U |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| Type of fuse status indicator (EF004473) | Top fuse status indicator |
| Insulated metal gripping lugs (IMGL) (EF012538) | - |
| Region Specific PriceGroup / Headquarter Price Group | 15I / 1DM |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.01.2014 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Lead CAS-No. 7439-92-1 > 0, 1 % (w / w)Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w):LeadBased on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation. |
Product Description
SITOR FUSE 630A AR 1000V MBC=6XIN ( ** ATTENTION : Price per 1 Unit and Minimum Quantity / Order Multiple 3 Units ** ). Manufactured to order. Non-Cancelable Non-Returnable.
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w):
