3NC2211-0MK
3NC2211-0MK SIEMENS SITOR cylindrical fuse link, 22x58 mm, 125 A, aR, Un AC: 690 V, Un DC: 250 V
$0.00USD
3388 in stock
Key Specifications
:
EAN:4001869497242
UPC:Not available
ETIM:5
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4001869497242 |
| UPC | Not available |
| ETIM | 5 |
| UNSPSC | 14 |
| eClass | 6 |
| Group Code | P310 |
| net weight | 60 g |
| Confirmation | Miscellaneous |
| Date5/8/2022 | |
| Metal Factor | LHB----- |
| Product Group | 5540 |
| Product class | C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit. |
| Quantity Unit | 1 Piece |
| Commodity Code | 85361090 |
| Product family | Cylindrical Fuse Design |
| Net Weight (kg) | 0,056 Kg |
| Size (EF000088) | 22x58 mm |
| Country of origin | Czech Republic |
| mounting position | Any, preferably vertical |
| LKZ_FDB/ CatalogID | LV10 |
| Packaging Quantity | 1 |
| product brand name | SENTRON |
| Packaging Dimension | 48,00 x 115,00 x 58,00 |
| Product Description | SITOR cylindrical fuse link, 22x58 mm, 125 A, aR, Un AC: 690 V, Un DC: 250 V |
| product designation | SITOR cylindrical fuse link |
| size of the fuse link | 22x58 mm |
| Minimum order quantity | 10 |
| supply voltage / at DC | 250 V |
| Product Lifecycle (PLM) | PM300:Active Product |
| Voltage type (EF000187) | AC |
| With striker (EF008175) | false |
| General Product Approval | Declaration of Conformity |
| Rated voltage (EF003977) | ['10', '690'] |
| Rated voltage (EF007681) | 690 |
| Export Control Regulations | AL : N / ECCN : N |
| Nominal current (EF000001) | 125 |
| Standard lead time ex-works | 5 Day/Days |
| Surcharge for Raw Materials | None |
| product component / striker | No |
| Breaking capacity (EF005617) | - |
| Package size unit of measure | MM |
| Utilization category (EF002572) | aR (accompanied semiconductor protection) |
| operating class of the fuse link | aR |
| Release characteristic (EF000889) | - |
| operational current / rated value | 125 A |
| Rated operating frequency (EF007370) | ['62', '45'] |
| Article Number (Market Facing Number) | 3NC2211-0MK |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| operating voltage / at AC / rated value | 690 V |
| operational current / at AC / rated value | 125 A |
| type of voltage / of the operating voltage | AC |
| Region Specific PriceGroup / Headquarter Price Group | 15I / 1DM |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.09.2013 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
| General Product ApprovalDeclaration of ConformityotherConfirmationMiscellaneousUK Declaration of ConformityMiscellaneous | General Product Approval |
Product Description
PROTEC FUSE. SEMICOND. SITOR 22X58 125A AR 690V AC/250V DC ( ** ATTENTION : Price per 1 Unit and Minimum Quantity / Order Multiplication 10 Units ** ). Manufactured to order. Non-Cancelable Non-Return
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Confirmation
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
